ASSEMBLY AND INSTALLATION
INSTRUCTIONS
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. READ AND SAVE THESE INSTRUCTIONS.
W0350
WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
Turn off the power at fuse or circuit box
190724
Hardware Package (included):
Headless Screw (D)Mounting Screw (B)Wire Connector (C)
Lock Nut (E)
Mounting plate (A)Ball Nut (F)
Ball Nut (F)
Glass Shade
Glass Holder
Socket Ring
Type A Max.60 W
or ST Vintage Bulb
(not included)
House Ground Wire
Green Ground Screw
Fixture Ground Wire
Wire Connector (C)
Mounting Screw (B)
Headless Screw (D)
Mounting Plate (A)
Outlet Box
Fixture Wire
Lock Nut (E)
Back Plate
Installation Steps
1. Thread two headless screws (D) through the mounting plate (A),
then secure them with four lock nuts (E) (two on each side of the
mounting plate). Adjust the length of the headless screws (D) if
necessary.
Note: Make sure that the headless screws are lined up
horizontally, in order to ensure that the fixture will be
level.
2. Attach the mounting plate (A) to the outlet box by using two
mounting screws (B).
