ASSEMBLY AND INSTALLATION
INSTRUCTIONS
T0734 / T0735
Maximum Wattage: 60W Bulb
Working Temperature: - 22°F~113°F
1. Read all instructions carefully before installation and
operation.
2. If you are not familiar with state and local electrical codes,
it is recommended that you consult with a qualified
electrician.
3. Before installation, shut off power at the main fuse or
circuit breaker box. Be aware that simply turning off the
wall switch is not sufficient to prevent an electrical shock.
4. This fixture requires a 120V AC, 60 Hz power source.
5. Do not attempt to take the lantern apart; there are no
serviceable parts inside.
6. To avoid sensor damage by lightning or electrical surge,
make sure the ground wire is securely connected.
7. For general safety and to avoid any possible damage to
the sensor, be sure the power is switched "off" before
replacing the bulb.
8. Compatible with most LED dimmable bulbs.
Hardware Package (included)：
Important to Know
Features
W
NOTE: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. Read
and save these instructions.
Page 1 / 4
1. Energy saving fixture.
2. When in manual override mode, use wall switch
to keep the light ON till dawn.
Mounting Screw (B)
Wire Connector (C)Bolt Nut (D)
Mounting Plate Unit (A)
Rubber Pad (E)
Wire Connector (C)
House Ground Wire
Outlet Box
Mounting Screw (B)
Green Ground Screw
Fixture Mounting Screw
Mounting Plate Unit (A)
Fixture Wire
Fixture Ground Wire
Rubber Pad (E)
Bolt Nut (D)
Backplate
Threaded Pipe
Rubber Pad-a
Dome
Bolt Nut-a
Max. 60W Type A Bulb
(not included)
WARNING: Turn off the main power at circuit breaker before installing fixture.
231011
