ASSEMBLY AND INSTALLATION
INSTRUCTIONS
W0551
W
NOTE: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. Read
and save these instructions.
WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER WHILE INSTALLING OR SERVICING THIS FIXTURE.
Hardware Package (
included
):
Mounting Screw (B)
Wire Connector (C) Bolt Nut (D)
Mounting Plate Unit (A)
House Ground Wire
Outlet Box
Mounting Screw (B)
Green Ground Screw
Fixture Mounting Screw
Wire Connector (C)
Mounting Plate Unit (A)
Fixture Wire
Fixture Ground Wire
Backplate
Bolt Nut (D)
Max. 40W Candelabra
Base Bulb
Socket Ring
Shade
Socket
1. Unscrew the two bolt nuts (D), remove the mounting plate unit (A) from the backplate.
2. Attach the mounting plate unit (A) to the outlet box by using two mounting screws (B). Adjust the length of the
preinstalled fixture mounting screws if necessary.
Note: Make sure that two fixture mounting screws are lined up vertically make the fixture level.
Turn off the power at fuse or circuit box.
Installation Steps
Page 1 / 2
250818
