For operations and guides to help you using your video monitor,

and for latest information and supports, go and check the online

help topics and online FAQs.

Use your smartphone or mobile device to access our online help.

• Go to https://help.vtechphones.com/vm818hd; OR

https://help.vtechphones.com/vm818-2hd

• Scan the QR code on the right. Launch the camera app or QR code scanner app

on your smartphone or tablet. Hold the device’s camera up to the QR code and

frame it. Tap the notification to trigger the redirection of the online help.

-If the QR code is not clearly displayed, adjust your camera’s focus by moving

your device closer or further away until it is clear.

You can also call our Customer Support at 1 (800) 595-9511 [in US] or

1 (800) 267-7377 [in Canada] for help.

NOTESNOTE

• The rechargeable battery in the parent unit is built-in.

• Use only the power adapters supplied with this product.

• Make sure the parent unit and the baby unit are not connected

to the switch controlled electric outlets.

• Connect the power adapters in a vertical or floor mount position

only. The adapters’ prongs are not designed to hold the weight

of the parent unit and the baby unit, so do not connect them to

any ceiling, under-the-table, or cabinet outlets. Otherwise, the

adapters may not properly connect to the outlets.

• Make sure the parent unit, the baby unit and the power adapter

cords are out of reach of children.

• To maintain compliance with the FCC’s RF exposure guidelines,

place the baby unit at least 20cm from nearby persons.

Specifications are subject to change without notice.

© 2022 VTech Communications, Inc. All rights reserved.

05/22. VM818HD_QSG_V1.

VM818HD

VM818-2HD

Full Color

HD Video Monitor

Go to www.vtechphones.com

to register your product for enhanced

warranty support and the latest VTech

product news.

1

Connect the baby monitor

2

Power on or off the baby monitor

What’s in the box

4

Status check

Once you power on both your

baby unit and parent unit, your

parent unit displays image from

the baby unit, and the LINK LED

light turns on.

The green LED light of the

baby unit turns on.

3

Positioning the baby monitor

Caution

• The default volume of your parent unit is level

3, and the maximum volume is level 5. If you

experience high-pitched screeching noise from

your baby monitor while positioning:

-Make sure your baby unit and parent unit are

more than 3 feet (1 meter) apart, OR

-Lower the volume of your parent unit.

NOTESNOTE

Note

• To avoid interference from other electronic

devices, place your baby monitor at least 3 feet

(1 meter) away from devices such as wireless

routers, microwaves, cell phones and computers.

Use the menu

Press MENUto enter the menu, choose a

menu item, or save a setting. You can use

the parent unit for advanced settings or

operations, such as to play or stop the baby

unit lullaby, or to adjust the baby unit sound

sensitivity.

While in the menu:

• Press , , or to scroll among the

menu options.

• Press SELECT to select an item, or to save

a setting.

• Press TALK to return to the live video.

• Press to go to the Help & info page.

Basic operation - Parent unit

Overview - Parent unit

Overview - Baby unit

Transmit frequencyBaby unit: 2405 - 2475MHz

Channels32

LCD5’’ Color LCD

(IPS 1280x720 pixels)

Nominal effective rangeMaximum power allowed by FCC and IC. Actual operating range

may vary according to environmental conditions at the time of use.

Power requirementsBaby unit power adapter: Output: 5V DC, 1A.

Parent unit power adapter: Output: 5V DC, 2A.

Parent unit battery: 3.7V 5000mAh, 18.5Wh Lithium-ion battery

Technical specifications

The applied nameplate is located at the bottom of the baby

unit’s base.

When using your equipment, basic safety precautions

should always be followed to reduce the risk of fire, electric

shock and injury, including the following:

1. Follow all warnings and instructions marked on the

product.

2. Adult setup is required.

3. CAUTION: Do not install the baby unit at a height above

2 meters.

4. This product is intended as an aid. It is not a substitute for

responsible and proper adult supervision and should not be

used as such.

5. This product is not intended for use as a medical monitor .

6. Do not use this product near water. For example, do not

use it next to a bath tub, wash bowl, kitchen sink, laundry

tub or swimming pool, or in a wet basement or shower.

7. CAUTION: Use only the battery provided. There may be a risk

of explosion if a wrong type of battery is used for the parent

unit. The battery cannot be subjected to high or low extreme

temperature and low air pressure at high altitude during use,

storage or transportation. Disposal of battery into fire or a hot

oven, or mechanically crushing or cutting or the battery can

result in an explosion. Leaving the battery in an extremely

high temperature surrounding environment can result in an

explosion or the leakage of flammable liquid of gas. Battery

subjected to extremely low air pressure may result in an

explosion or the leakage of flammable liquid or gas. Dispose of

used battery according to the information in The RBRC seal.

8. Use only the adapters included with this product.

Incorrect adapter polarity or voltage can seriously

damage the product.

Power adapter information:

Parent unit output: 5V DC 2A

VTech Telecommunications Ltd.

Model: VT07EUS05200

Baby unit output: 5V DC 1A.

VTech Telecommunications Ltd.

Model: VT05EUS05100

Rechargeable battery information:

Li-ion battery, 3.7V 5000mAh, 18.5Wh

Zhuhai Great Power Energy Co., Ltd.

Model Number: GSP806090-5Ah-3.7V-1S1P

9. The power adapters are intended to be correctly oriented

in a vertical or floor mount position. The prongs are not

designed to hold the plug in place if it is plugged into a

ceiling, under-the-table or cabinet outlet.

10. For pluggable equipment, the socket-outlet shall

be installed near the equipment and shall be easily

accessible.

11. Unplug this product from the wall outlet before cleaning.

Do not use liquid or aerosol cleaners. Use a damp cloth for

cleaning.

12. Do not cut off the power adapters to replace them with

other plugs, as this causes a hazardous situation.

13. Do not allow anything to rest on the power cords. Do not

install this product where the cords may be walked on or

crimped.

14. This product should be operated only from the type

of power source indicated on the marking label. If you

are not sure of the type of power supply in your home,

consult your dealer or local power company.

15. Do not overload wall outlets or use an extension cord.

16. Do not place this product on an unstable table, shelf, stand

or other unstable surfaces.

17. This product should not be placed in any area where

proper ventilation is not provided. Slots and openings

in the back or bottom of this product are provided for

ventilation. To protect them from overheating, these

openings must not be blocked by placing the product

on a soft surface such as a bed, sofa or rug. This product

should never be placed near or over a radiator or heat

register.

18. Never push objects of any kind into this product through

the slots because they may touch dangerous voltage

points or create a short circuit. Never spill liquid of any

kind on the product.

19. To reduce the risk of electric shock, do not disassemble

this product, but take it to an authorized service facility.

Opening or removing parts of the product other than

specified access doors may expose you to dangerous

voltages or other risks. Incorrect reassembling can

cause electric shock when the product is subsequently

used.

20. You should test the sound reception every time you turn

on the units or move one of the components.

21. Periodically examine all components for damage.

22. There is a very low risk of privacy loss when using certain

electronic devices, such as baby monitors, cordless

telephones, etc. To protect your privacy, make sure the

product has never been used before purchase, reset

the baby monitor periodically by powering off and then

powering on the units, and power off the baby monitor

if you will not use it for some time.

23. Children should be supervised to ensure that they do not

play with the product.

24. The product is not intended for use by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning

use of the appliance by a person responsible for their

safety.

SAVE THESE INSTRUCTIONS

Cautions

1. Use and store the product at a temperature between 32

o

F

and 104

o

F.

2. Do not expose the product to extreme cold, heat or

direct sunlight. Do not put the product close to a heating

source.

3. Batteries should not be exposed to excessive heat such as

bright sunshine or fire.

4. Warning—Strangulation Hazard—

Children have STRANGLED in cords. Keep

this cord out of the reach of children (more

than 3 ft (0.9m) away). Do not remove this

tag.

5. Never place the baby unit(s) inside the baby’s crib or

playpen. Never cover the baby unit(s) or parent unit with

anything such as a towel or a blanket.

6. Other electronic products may cause interference

with your baby monitor. Try installing your baby

monitor as far away from these electronic devices

as possible: wireless routers, radios, cellular

telephones, intercoms, room monitors, televisions,

personal computers, kitchen appliances and cordless

telephones.

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless devices):

Wireless Technology Research, LLC (WTR), an independent

research entity, led a multidisciplinary evaluation of the

interference between portable wireless devices and

implanted cardiac pacemakers. Supported by the U.S. Food

and Drug Administration, WTR recommends to physicians that:

Pacemaker patients

• Should keep wireless devices at least six inches from the

pacemaker.

• Should NOT place wireless devices directly over the

pacemaker, such as in a breast pocket, when it is turned ON.

WTR’s evaluation did not identify any risk to bystanders with

pacemakers from other persons using wireless devices.

Electromagnetic fields (EMF)

This VTech product complies with all standards regarding

electromagnetic fields (EMF). If handled properly and

according to the instructions in this user’s manual, the product

is safe to be used based on scientific evidence available today.

Important safety instructions

1LINK LED light

2

LED light

33- level sound indicator

light

4

TALK /

• Press and hold to talk to

the baby unit.

• While in a submenu,

press to exit.

5

• Press to zoom in/out.

• When in the main menu,

press to go to the

Help & Info page.

6Arrow keys

7MENU/SELECT

• Press to enter the main

menu.

• While in a menu, press to

choose an item, or save a

setting.

8- VOL/ VOL +

• Increase or decrease

parent unit’s volume.

9Microphone

10Speaker

11POWER / LCD ON/OFF

12Power jack

13RESET

Force reboot the parent

unit.

14Antenna

15Stand

1Infrared LEDs

2Camera lens

3Light sensor

4Microphone

5Night light

6

Night light ON/OFF key

7LED indicator

8Power ON/OFF switch

9Speaker

10Antenna

11Power jack

12Temperature sensor

Position the sensor horizontally for

optimal usage.

Caution

• Do not bend the temperature sensor

upward.

13Slots for wall mounting

14Pair button

Need help?

S

m

Parent unit icons

Main menu

Monitoring mode (* For VM818-2HD only)

• View baby units in Single mode.

• View baby units in Patrol mode.

• View baby units in Split screen.

Melodies and soothing sounds

Melodies and Soothing Sounds

• Select play all melodies, or play one of the

five melodies and four soothing sounds.

Timer

• You can also set the timer to stop playing

after 15, 30 or 60 minutes, or playing non-

stop.

Alerts - Sound, motion and temperature

Sound

• Select sound Sensitivity level.

• Turn on/off Sound Detection Alert.

• Turn on/off Auto Wake Up function.

(See Sound Detection and Auto Wake Up

section)

Motion

• Turn on/off Motion Alert.

• Select motion Sensitivity level.

(See Motion Detection section)

Main menu

Temperature

• Turn on/off Temperature Alert.

Set the parent unit to beep whenever the

room temperature detected by the baby

unit falls outside of the set temperature

range.

• Select Minimum temperature for alert

range.

• Select Maximum temperature for alert

range.

• Select temperature Format.

Set temperature display in Fahrenheit (

o

F)

or Celsius (

o

C

).

Parent unit settings

• Adjust parent unit screen Brightness.

• Turn on/off Dim Mode.

Baby unit settings

• Turn on/off Night Light.

• Turn on/off baby unit’s Status LED.

• Adjust baby unit’s speaker Volume.

General settings

• Turn on/off Low Battery Alert Tone.

Set the parent unit to beep when the

battery is low.

• Turn on/off No Link Alert Tone.

Set the parent unit to beep when the link

between the parent unit and the baby unit

is lost.

Main menu icons

VM818HD

Quick start guide

VM818HDVM818-2HD

VM818-2HD

For more support information

S

m

x 2

x 2

Quick start guide

Strangulation

Hazard

Keep this cord out of reach of children.

The cord needs to be at least three feet

away from the child at all times. Do not

use with an extension cord. Do not

remove this tag.

Éloignez ce cordon des enfants. Le

cordon doit se trouver à au moins trois

pieds d’un enfant et ce, en tout temps.

N’utilisez pas de rallonge. Ne retirez pas

cette étiquette.

Mantenga este cable fuera de la alcance

de los niños. Este cable debe estar por

lo menos tres pies fuera de la alcance

del niño en todo momento. No lo use

con una extensión inalámbrica. No quite

esta etiqueta.

Risque

d’étranglement

Riesgo de

estrangulación

Charge the parent unit battery before use

When you have connected and turned on the parent unit, the battery will be charged

automatically.

NOTESNOTE

Notes

• Before using the baby monitor for the first time,

charge the parent unit battery for 12 hours.

When the parent unit battery is fully charged,

the battery icon becomes solid .

• It takes longer to charge the battery when the

parent unit is turned on. To shorten the charging

time, turn the parent unit off while charging.

• The standby time varies depending on the

sensitivity level you set, your actual use and the

age of the battery.

The battery icon indicates the battery status (see

the following table).

Battery indicatorsBattery statusAction

The screen displays .

The light flashes.

The battery has very little

power and may be used for

only a short time.

Charge

without interruption

(about

30 minutes).

The battery icon becomes

solid .

The battery is fully charged.To keep the battery charged, connect

it to AC power when not in use.

Slide the ON/OFF switch leftward

to power on your baby unit.

After the parent unit is fully charged,

press POWER until the welcoming

screen appears.

Raise the parent unit antenna

for better reception

1

Connect the baby monitor (Cont’d)

< 3ft (1m)

> 3ft (1m)

≥

<

3ft (1m)

3ft (1m)

﹏﹏﹏﹏﹏﹏

﹏﹏﹏﹏﹏﹏

﹏﹏﹏﹏﹏﹏﹏﹏

﹏﹏﹏﹏﹏﹏﹏﹏

﹏﹏﹏﹏﹏﹏﹏﹏

﹏﹏﹏﹏﹏﹏﹏﹏﹏﹏

﹏﹏﹏﹏﹏﹏﹏﹏﹏﹏

﹏﹏﹏﹏﹏﹏﹏﹏﹏﹏

﹏﹏﹏

﹏﹏﹏

﹏﹏﹏﹏

﹏﹏﹏﹏

﹏﹏﹏﹏

﹏﹏﹏﹏﹏

﹏﹏﹏﹏﹏

﹏﹏﹏﹏﹏

Adjust speaker volume

Press -VOL / VOL+ to adjust your parent unit

speaker volume. It determines the volume of

sound transmitted from your baby unit.

Zoom

Press to zoom in or out.

Talk to your baby via the baby unit

1. Press and hold the TALK key.

2. When the icon displays on screen,

speak to your parent unit. Your voice is

transmitted to the baby unit.

3. When finish talking, release

the TALK key and hear your baby again.

Turn on/off the parent unit screen

You can turn on or off the parent unit

screen without powering off the parent

unit. You can still hear sound from the

baby unit.

• Press POWER on the parent unit to

turn off the screen.

• Press any keys on the parent unit to

turn on the screen again.

Alert icons

• Displays when parent unit’s battery is low and

needs charging.

• Displays when motion is detected at a baby unit.

• Displays when sound is detected at a baby unit.

• Baby unit detects temperature exceeds the set

maximum.

• Baby unit detects temperature is lower than the

set minimum.

UL STD.

62368-1

CERTIFIED TO

CSA STD.

C22.2 NO.62368-1

CONFORMS TO

> 3ft (1m)

Press and hold

2

1

3

4

5

6

7

8

9

15

12

11

10

13

14

1

2

3

9

4

5

10

6

7

12

11

14

13

8

1

2

3

9

4

5

10

6

7

12

11

14

13

8

1

2

3

9

4

5

10

6

7

12

11

14

13

8

Caution

• Position the baby unit’s temperature

sensor horizontally for its optimal

usage. Do not bend it upward.

Current view status

Strong Signal

Fair Signal

Low Signal

No Signal

Night vision

feature is activated

automatically.

Motion alert is turned

on.

Sound detection

alert is turned on.

Melodies or soothing

sound are turned on.

Night light is turned

on.

Parent unit speaker is

muted.

Temperature alert is

turned on.

70

F

F

Temperature is

lower than user-set

minimum.

Temperature is

between user-set

comfortable range.

Temperature is

higher than user-set

maximum.

Battery status

indicator

˚˚

FF

˚˚

FF

˚˚

FF

Status icons

1 set for VM818HD

2 sets for VM818-2HD

Product specificaties
