FrequencyBaby unit: 2402 - 2480 MHz ( WiFi, FHSS, BLE )

Max Transmit power is 10mW ( WiFi, FHSS, BLE )

Parent unit: 2406 - 2475 Mhz

Max Transmit power is 100mW

LCD5.5’’ Color LCD (IPS 1280 x 720 pixels)

Nominal effective rangeMaximum power allowed by FCC and IC. Actual operating range may

vary according to environmental conditions at the time of use.

Power requirementBaby unit power adapter: Output: 5V DC, 1A

Parent unit power adapter: Output: 5V DC, 2A

Parent unit battery: 3.7V 5000mAh, 18.5Wh Lithium-ion battery

Specifications are subject to change without notice.

© 2024 VTech Communications, Inc.

All rights reserved. 10/24. RM6756HD_US_QSG_V1

Technical specications

Android

TM

and Google Play

TM

are trademarks of Google Inc.

App Store is a trademark of Apple Inc., registered in the U.S. and other countries.

IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license.

UL STD.

62368-1

CERTIFIED TO

CSA STD.

C22.2 NO.62368-1

CONFORMS TO

Disclaimer and Limitation of Liability

VTech Communications, Inc. and its suppliers assume no responsibility for any damage or loss

resulting from the use of this user’s manual. VTech Communications, Inc. and its suppliers assume no

responsibility for any loss or claims by third parties that may arise through the use of this product.

Company: VTech Communications, Inc.

Address: 9020 SW Washington Square Road - Ste 555 Tigard, OR 97223, United States

Phone: 1 (800) 595-9511 in the U.S. or 1 (800) 267-7377 in Canada

Cable management

123

What’s in the box

x 2

x 2

Quick start guide

Congratulations

on purchasing your new VTech product.

Before using this baby monitor, please read the Important safety instructions.

RM6756HD

5.5” Smart High-Definition

Video Monitor

Quick start guide

Go towww.vtechbabycare.com

to register your product for

enhanced warranty support and

latest VTech product news.

For more support information

S

m

Strangulation

Hazard

Keep this cord out of reach of children.

The cord needs to be at least three feet

away from the child at all times. Do not

use with an extension cord. Do not

remove this tag.

Éloignez ce cordon des enfants. Le

cordon doit se trouver à au moins trois

pieds d’un enfant et ce, en tout temps.

N’utilisez pas de rallonge. Ne retirez pas

cette étiquette.

Mantenga este cable fuera de la alcance

de los niños. Este cable debe estar por

lo menos tres pies fuera de la alcance

del niño en todo momento. No lo use

con una extensión inalámbrica. No quite

esta etiqueta.

Risque

d’étranglement

Riesgo de

estrangulación

Product Recycling

Recycle this product when you are done with it.

For more information, scan the QR code

or visit www.vtechbabycare.com.

Overview

Baby unit overview

1Light sensor

2Camera lens

3Infrared LEDs

• Allow you to see clearly in a dark environment.

4Microphone

5Night Light

6

Night Light Control Key

• Single Tap: Turn on/off.

• Tap and hold (with the light turned on):

Adjust night light brightness.

7

ON/OFF switch

8

LED indicator

Set to off by default. You can turn it on using the

app (Setting > Camera Setting > LED status).

In direct mode:

• Orange is steadily on when the baby unit is

connecting to the parent unit.

• Orange flashes slowly during video streaming.

In Wi-Fi mode:

• Green is steadily on when the baby unit is

connected to Wi-Fi.

• Green flashes slowly during video streaming to

Wi-Fi.

9

Speaker

10

Temperature sensor

11

PAIR

• To enter pairing mode, press and hold the

PAIR key for three seconds until you hear a

beep sound. Then follow the app instructions

to connect the camera to a 2.4GHz Wi-Fi

network.

• To reset the baby unit, press and hold the

PAIR key until you hear a beep sound. Release

the PAIR key and then press and release a

further five times until you hear another beep

sound. The baby unit will emit another beep

when the reset is complete. After the beep

sound, the baby unit will reboot itself.

12

Power jack

13

Wall mount slots

Parent unit overview

1LINK LED light

• On when the parent unit is linked to the

baby unit.

• Flashes when the link to the baby unit is lost.

2

LED light

• On when the parent unit is connected to

AC power, and the battery is charging.

• Flashes when the parent unit battery is

low and needs to be charged.

33- level sound indicator light

The lights indicate different sound levels

detected from the baby unit.

• Green light: low sound level.

• Green and amber lights: moderate sound

level.

• Green, amber, and red lights: high sound

level.

4

TALK /

• Press and hold to talk to the baby unit.

is displayed on screen while the

button is pressed.

• While in a sub-menu, press to exit.

5MENU

|

SELECT

• Press to toggle between black-and-white

night vision and color night vision mode.

• Press twice to enter the main menu when

the parent unit is idle.

• While in a menu, press to confirm a

selection, or save a setting.

6

|

|

|

Arrow keys

• Press to navigate leftward, upward,

rightward or downward, within the main

menu and sub-menus.

• While viewing a zoomed image, press

to move the image leftward, upward,

rightward or downward.

7Microphone

8

|

• Increase, decrease or mute the parent

unit volume.

9

Zoom

• Press to zoom in/out to different levels.

10

Power

|

LCD ON/OFF

• Press and hold to turn on/off the power.

• Press to turn on/off the LCD screen.

11Antenna

12Speaker

13Power jack

14RESET

• Force reboot the parent unit.

15Stand

2

1

3

4

5

6

7

8

9

10

14

15

13

12

11

Download app for mobile access

The applied nameplate is located at the bottom of the baby unit base.

When in use, basic safety precautions should always be followed

to reduce the risk of fire, electric shock and injury, including the

following:

1. Follow all warnings and instructions marked on the product.

2. Adult setup is required.

3. CAUTION: Do not install the baby unit at a height above 6.5 feet

(2 meters).

4. This product is intended as an aid. It is not a substitute for

responsible and proper adult supervision and should not be

used as such.

5. This product is not intended for use as a medical monitor.

6. Do not use this product near water, for example, near to a bath,

sink, swimming pool or shower.

7. CAUTION: Use only the internal, non-user replaceable battery

fitted to the parent unit. There may be a risk of explosion if a

wrong type of battery is used for the parent unit. The battery

cannot be subjected to high or low extreme temperature

and low air pressure at high altitude during use, storage or

transportation. Disposal of batteries in fire or a hot oven,

mechanically crushing or cutting the battery can result in an

explosion. Subjecting products or batteries to an extremely high

temperature environment can result in explosion or leakage of

flammable liquids, or gas. Products or batteries subjected to

extremely low air pressures may result in explosion or leakage of

flammable liquids, or gas. Dispose of used batteries according

to the information in The RBRC seal.

8. Use only the power adapters supplied with this product.

Incorrect power adapter polarity or voltage can seriously

damage the product.

Power adapter information:

Baby Unit Output: 5V DC 1A

VTech Telecommunications Ltd.

Model: VT05EUS05100

-OR-

Jiangxi Jian Aohai Technology Co., Ltd.

Model: A318-050100W-US2

Parent Unit Output: 5V DC 2A

VTech Telecommunications Ltd.

Model: VT07EUS05200

-OR-

Jiangxi Jian Aohai Technology Co., Ltd.

Model: A938-050200W-US1

Rechargeable battery information:

3.7V 5000mAh, 18.5Wh Lithium-ion battery

Zhuhai Great Power Energy Co., Ltd.

Model: GSP806090-5Ah-3.7V-1S1P

9. The power adapter is intended to be correctly oriented in a

vertical or floor mount position. The prongs are not designed to

hold the plug in place if it is plugged into a ceiling, under-the-

table or cabinet outlet.

10. For pluggable equipment, the socket-outlet (power adapter)

should be installed near the equipment and should be easily

accessible.

11. Unplug this product from the wall outlet before cleaning.

Do not use liquid or aerosol cleaners. Use a damp cloth for

cleaning.

12. Do not modify the power adapters or replace with other third-

party adapters.

13. Do not allow anything to rest on the power cords. Do not install

this product where the cords may be walked on or damaged.

14. The product should only be operated from a power source

indicated on the power adapter label or marking. If you are

unsure of the type of power supply in your home, consult your

dealer or electricity supply provider.

15. Do not overload wall outlets or use an extension cord.

16. Do not place this product on an unstable table, shelf, stand or

other unstable surfaces.

17. This product should not be placed in any area where proper

ventilation is not provided. Any slots or openings in the back or

bottom of this product are provided for ventilation. To protect

from overheating, openings must not be blocked by placing

the product on a soft surface such as a bed, sofa or rug. This

product should never be placed near or over a radiator or heat

source.

18. Never insert any objects through any apertures or slots in the

product as this can be dangerous and cause damage to the battery

or other internal parts. Never spill any liquids on the product.

19. To reduce the risk of electric shock, do not disassemble

this product, but take it to an authorized service facility.

Disassembling or removing parts of the product other than

battery replacement via a battery door (if applicable) may

expose dangerous voltages or other risks.

20. You should test the sound reception every time you turn on the

units or move one of the components.

21. Periodically examine all components for damage.

22. There is a very low risk of privacy loss when using certain

electronic devices, such as baby monitors, cordless telephones,

etc. To protect your privacy, make sure the product has

never been used before purchase, reset the baby monitor

periodically by powering off and then powering on the units,

and power off the baby monitor if you are not intending to use

it for some time.

23. Children should be supervised to ensure that they do not play

with the product.

24. The small parts of this monitor can be swallowed by babies or

small children. Keep these parts out of reach of children.

25. The product is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance

by a person responsible for their safety.

SAVE THESE INSTRUCTIONS

Cautions

• Use and store the product at a temperature between 32

o

F (0

o

C)

and 104

o

F (40

o

C).

• Mishandling batteries can cause burn, fire or explosion hazards.

• Batteries should not be exposed to excessive heat such as bright

sunshine or fire.

• Do not expose the product to extreme cold, heat or direct

sunlight. Do not place the product close to a heating source.

• Warning—Strangulation Hazard—Children

have STRANGLED in cords. Keep this cord out of the

reach of children (more than 3 ft (0.9m) away). Do not

remove warning label on the adapter cord.

• Never place the baby unit(s) inside the baby’s crib or playpen.

Never cover the baby unit(s) or parent unit with anything such as

a towel or a blanket.

• Other electronic products can cause interference to your parent

unit and baby unit. Try installing your baby unit as far away

as possible from the following electronic devices: wireless

routers, radios, mobile telephones, intercoms, room monitors,

televisions, personal computers, kitchen appliances (e.g.

microwave ovens) and cordless telephones.

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless devices):

Wireless Technology Research, LLC (WTR), an independent

research entity, led a multidisciplinary evaluation of the

interference between portable wireless devices and implanted

cardiac pacemakers. Supported by the U.S. Food and Drug

Administration, WTR recommends to physicians that:

Pacemaker patients

• Should keep wireless devices at least six inches from the

pacemaker.

• Should NOT place wireless devices directly over the pacemaker,

such as in a breast pocket, when it is turned ON.

WTR’s evaluation did not identify any risk to bystanders with

pacemakers from other persons using wireless devices.

Electromagnetic elds (EMF)

This VTech product complies with all standards regarding

electromagnetic fields (EMF). If handled properly and according to

the instructions in this user’s manual, the product is safe to be used

based on scientific evidence available today.

Important safety instructions

Parent unit icons

Main

Menu

Sub-

menu

Options

Night light

On/Off

• Toggle the night light on or off.

Color

• Select a night light color.

• Customized color is available if your

baby unit is paired with MyVTech

Baby Plus app.

Brightness

• Adjust the night light brightness.

• Set the brightness to AUTO

adaptive ambience.

Timer

• Set the timer to turn the night light

off after 15, 30 or 60 minutes, or

always on.

Main

Menu

Sub-

menu

Options

Melodies and soothing sounds

Play/Stop

• Toggle between play and stop.

Library

• Select to play all melodies, or play

one of the five melodies or five

soothing sounds.

Camera Volume

• Adjusts baby unit speaker volume.

Timer

• Set the timer to stop playing after 15,

30 or 60 minutes, or play non-stop.

General settings

Connect to Mobile App

• Instructions for adding baby unit to

mobile app.

Camera Volume

• Adjusts baby unit speaker volume.

Screen Brightness

• Adjusts parent unit screen

brightness.

Screen Off Timer

• Turn the screen off timer OFF, or

set the screen to turn off after 1,

3 or 5 minutes when no sound is

detected.

• Select AUTO to set the Sound

Sensitivity level for the screen to

auto turn on when a sound level is

detected that is higher than the set

level. The screen will turn off after 50

seconds of no sound detection.

Low Medium High

Status icons

Direct mode

Parent unit and baby unit are

connected to each other directly.

Signal strength is indicated by the signal

icon(s) on the right.

The red bar(s) indicates no connection.

Wi-Fi mode

The signal icon(s) on the left indicate

the baby unit is connected to a home

Wi-Fi network. The red icon(s) indicates

no connection.

Black and white night vision is turned on.

Color night vision is turned on.

Motion detection alert is turned on.

Melodies and soothing sounds are

playing.

Night light is turned on.

Auto night light brightness is activated.

Temperature alert is turned on.

Parent unit is muted.

Temperature measured at baby unit.

Battery level indicator

Low battery indicator

Use the MyVTech Baby Plus on your mobile device to monitor your baby

remotely. Follow the instructions below to set up and pair your baby monitor

with the app.

1. Scan the QR code to download the free MyVTech Baby Plus mobile app,

or search “MyVTech Baby Plus” on App Store or Google Play Store. If you

have previously installed the app, ensure that you have the latest version.

2. Tap

P

L

U

S

P

L

U

S

to launch the mobile app on your device and create an account.

3. We recommend that you use common webmail services, such as Google Gmail, to

register your user account. Check your email (including the Spam folder) and activate

your new account by entering the email verification code. Then, sign in to your account.

4. Ensure that you are connected to a 2.4GHz Wi-Fi network and have enabled Bluetooth

and Location Service on your device.

5. After signing in to the app, select Camera(s) with Parent unit and scan the QR code

displayed on the parent unit. To find the QR code, press the MENU/SELECT button and

go to > Connect to Mobile App.

6. Input the Wi-Fi password from the app.

7. Press and hold the pair key on the baby unit for 3 seconds until you hear the beep

sound to enter pairing mode.

8. Select the camera model that appears in the app and wait for the camera to connect.

Once connected, it will display a live view preview.

9. Select “Continue” and create a profile for your baby (optional). Now you can start

monitoring!

P

L

U

S

P

L

U

S

• Make sure your mobile device meets the

minimum requirement for the mobile app.

Minimum requirement

The mobile app is compatible with:

• Android

TM

9.0 or later (Not compatible

with mobile devices with a 32-bit Android

operating system); and

• iOS 14 or later.

Use Camera Sharing to instantly share access to the camera. Follow these steps:

1. Go to Menu and select Camera Sharing.

2. Choose “Invite People” and enter the name and email address of the family member’s app

account.

3. The family member will receive a pop-up notification in the app and can accept the

invitation to access the camera(s).

How the system works

Direct mode

Your baby monitor parent unit and baby unit connect to each other inDirect mode by

default, which allows you to immediately stream video out of the box.

You may experience reduced signal

strength if your parent unit and baby

unit are far apart, or there are

obstructing factors, such as internal

walls between them. Move the parent

unit closer to the baby unit to improve

the signal strength. Ensure the parent

unit antenna is raised for optimum

reception.

Wi-Fi mode

To enhance your experience and

enjoy seamless live video streaming

via your mobile app, and to receive

product software updates (when

available), we highly recommend

setting up your monitor’s Wi-Fi

connection.

It uses your 2.4GHz home Wi-Fi

network to connect your video

monitor and supports live video

streaming through the mobile app.

To stream live video remotely with

your mobile device, download

and install the MyVTech Baby Plus mobile app. With the mobile app, your Wi-Fi router (not

included) provides Internet connectivity to your HD video monitor system. It serves as a

communication channel between your baby unit and mobile device, allowing you to monitor

and/or control your baby unit wherever you are. For more details, see Download app for

mobile access section in this quick start guide.

FHSS link

To receive product rmware updates, this baby monitor requires connecting to a

2.4GHz home Wi-Fi network.

Mobile access

Local access

FHSS link

Connect, charge and power on the baby

monitor

1

2

3

7

8

9

10

4

6

3

5

2

11

12

13

1

7

8

9

10

4

6

3

5

2

11

12

13

1

7

8

9

10

4

6

3

5

2

11

12

13

1

Slide the switch to ON to power on the

baby unit.

Connect the parent unit and baby unit to the adapter and mains supply.

The parent unit turns on automatically after connection to the power socket.

WARM

WARM

• Please peel off the lens/screen protector before use.

• Charge the parent unit battery before use.

• When powering up, the baby unit’s orange status LED turns on. It will turn

off after a while and remain off if the status LED is set to off.

• The status LED is set to off by default. You can turn it on using the app

(Setting > Camera Setting > LED status).

• A steady orange light with no video or audio streaming can indicate a fault

condition.

• The baby unit may get warm during use. This is normal.

For optimum reception,

always raise the parent unit

antenna.

Main

Menu

Sub-

menu

Options

Temperature Format

• Set the temperature display format

between Celsius or Fahrenheit.

Other

• Time Settings (available when

pairing your baby monitor to the

MyVTech Baby Plus app), Reset

Settings, Software Update.

Alerts Settings

• Adjusts the alert tone volume level.

Motion Detect

• Turn the motion detection alert on/

off.

• Adjust Motion Sensitivity level for

waking the parent unit screen.

Low Medium High

Temperature

• Turn the temperature alert on/off.

• Select the temperature alert

maximum and minimum

temperature limits.

Low Battery

• Toggle the low battery alert on or

off.

Lost Link

• Toggle the lost link alert on or off.

Help and info

Help

• Support Information

How-to Video

• Support video

System Info

• System Information

Overlay Control Panel

Main Menu

Night Modes

• Turn on night light for 30s in color

night mode.

• Adjust night light brightness.

Main Menu Icons

• Select black-and-white night

vision for extreme darkness or

color night vision for dim

environments (the use of the

baby unit night light or other

supplementary light sources are

required).

Product specificaties
