ASSEMBLY AND INSTALLATION
INSTRUCTIONS
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. READ AND SAVE THESE INSTRUCTIONS.
W0337
Hardware Package (included):
WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
190514
1. Remove the set screws (D) and to separate the mounting plate (A) from the fixture.
2. Attach the mounting plate (A) to the outlet box with two mounting screws (B).
3. Pull out the outlet wires and house ground wire from the outlet box.
Make wire connections using the wire connectors (C):
---Connect the black wire from the fixture to the black wire from the power source.
---Connect the white wire from the fixture to the white wire from the power source.
---Secure the fixture ground wire to the mounting plate (A) with the green ground screw.
Then connect it to the house ground wire with a wire connector (C).
Carefully put the wires back into the outlet box.
Turn off the power at fuse or circuit box
Installation Steps
House Ground Wire
Green Ground Screw
Wire Connector (C)
Mounting Screw (B)
Mounting Plate (A)
Outlet Box
Fixture Wire
Set Screw (D)
Mounting Screw (B)Wire Connector (C)Mounting Plate (A)
Set Screw (D)
Fixture
Bulb Type B Max. 60W
(not included)
