Page 1/4
ASSEMBLY AND INSTALLATION
INSTRUCTIONS
WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
T0385
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. Read and save these instructions.
Features
1. Energy saving fixture.
2. Use the dim-to-bright illumination option where
you want some minimum illumination through out
the night, such as at your front entrance or garage
door. Use the dark-to-bright illumination option
where you do not need minimum brightness, such
as the backyard or back porch.
3. When in manual override mode, use wall switch
to keep the light ON till dawn.
Mounting Screw (B)
Green Grounding
Screw (C)
Lock Nut (E)
Wire Connector (F)
Ball Nut (G)
Rubber Pad (H)
Cross Bar (A)
Important to Know
1. Read all instructions carefully before installation and operation.
2. If you are not familiar with state and local electrical codes, it is
recommended that you consult with a qualified electrician.
3. Before installation, shut off power at the main fuse or circuit
breaker box. Be aware that simply turning off the wall switch is
not sufficient to prevent an electrical shock.
4. This fixture requires a 120 VAC, 60 Hz power source.
5. Do not attempt to take the lantern apart; there are no
serviceable parts inside.
6. To avoid sensor damage by lightning or electrical surge, make
sure the grounding wire is securely connected.
7. For general safety and to avoid any possible damage to the
sensor, be sure the power is switched "off" before replacing the
bulb.
8. Compatible with LED dimmable bulb.
Maximum Wattage: 60W Incandescent Bulb or 20W LED
dimmable bulb.
Work Temperature: -4°F~104°F
Hardware Package (included):
Green Grounding Screw (C)
Outlet Box
Wire Connector
(F)
Headless Screw (D)
Cross Bar (A)
Lock Nut
(E)
House Grounding Wire
Fixture Grounding Wire
Bulb Type A Max.60W or
20W LED dimmable bulb
(not included)
Mounting Screw (B)
Fixture
Back Plate
Ball Nut(G)
Rubber Pad(H)
Headless
Screw (D)
Fixture Wire
240703
