1 947826
CAUTION: To reduce the risk of electric shock,
Do not remove cover.
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
Issue 1
VIP-480AL IP One-Way Horn
INTRODUCTION
The VIP-480AL IP One-way Horn provides for
one-way communication when used in a Valcom
VoIP based intercom/paging system.
SPECIFICATIONS
Access Methods
PBX, FXO Port w/VIP-81X
POTS telephone set w/VIP-81X
FXS Port w/VIP-82X
SIP telephone system
Features
RJ-45 for network connection
LED Status Indicator
Network activity LEDs
Power over Ethernet (PoE) 802.3af compatible
Dimensions/Weight
Horn–
6.80” H x 8.30” W x 3.30” D
(17.27 cm) x (21.08 cm) x (8.38 cm)
Weight: 2.10 lbs. (0.95 kg)
Network Interface
1.62” H x 5.63” W x 3.45” D
(4.11 cm) x (14.30 cm) x (8.73 cm)
with brackets– 8.22” W (20.87 cm)
Weight: 2.10 lbs. (0.95 kg)
Nominal Power Requirements
Via 802.3af PoE Ethernet Switch: Class 3
Environment
Network Interface:
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
Horn:
Suitable for indoor or outdoor installation
Packing List
Precautionary Designations
QtyItem
1 Network Interface
1 VIP-480AL Horn
1 VSP Document
1 VM-186 RJ-45 Connector
4 Wood Screws
1 “C” Clamp
