1 947762

Issue 3

VIP-402A, VIP-402A-EC

LAY-IN ONE-WAY IP CEILING SPEAKER

INTRODUCTION

The VIP-402A / VIP-402A-EC Lay-In One-way IP

Ceiling Speakers enable voice access to a single

zone of paging over an IP-based network. This

allows a page zone extension anywhere on the

network. The speaker output level is electrically

adjusted during setup. The lay-in ceiling speaker

grille is made of steel with a white baked enamel

finish. The VIP-402A replaces a 2’ x 2’ ceiling tile.

The VIP-402A-EC replaces a 600mm x 600mm

ceiling tile. Power is provided to the unit via a

Power over an Ethernet (PoE) switch meeting the

802.3af specification.

SPECIFICATIONS

Access Methods

PBX, FXO Port w/VIP-811

POTS telephone set w/VIP-811

PBX, FXS Port w/VIP-821

Valcom M Cast Page Group

SIP – enabled telephone system

Features

RJ-45 network connection

Power over Ethernet (PoE) 802.3af compliant

High Efficiency Class-D Amplifier



Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

Packing List

Qty. Item

1 Lay-in Ceiling Speaker

1 VSP Document

INSTALLATION

Dimensions/Weight

VIP-402A:

23.75” L x 23.75” W x 3.75” D

(60.33cm) x (60.33cm) x(9.53cm)

Weight: 5.5 lbs. (2.49kg)

VIP-402A-EC:

594cm L x 594cm W x 9.53cm D

Weight: 2.49kg

FCC Information

This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when

the equipment is operated in a commercial

environment. This equipment generates uses,

and can radiate radio frequency energy and if

not installed and used in accordance with the

instruction manual, may cause harmful

interference to radio communications.

Operation of this equipment in a residential area

may cause harmful interference in which case

the user will be required to correct the

interference at his own expense.
