Issue 1

1 947103

CAUTION: To reduce the risk of electric shock,

Do not remove cover (or back).

No user serviceable parts inside.

Refer servicing to qualified service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

VIP-142

High Power Paging ornIP Talkback H

INTRODUCTION

The VIPHorn is a weather-142 PagingIP -

resistant, high-efficiency horn supporting

multiple audio and control protocols, all

delivered via a PoEenabled IP network. A -

separate microphone facilitates full-duplex

talkback cThe highommunication. -impact

Polycarbonate construction resists the

deteriorating effects of outdoor installation.

SPECIFICATIONS

Access Methods

•SIP telephone system

• Valcom M Cast Page Group

•-A PBX, FXO Port w/VIP811

•P-A OTS telephone set w/VIP811

•-A PBX, FXS Port w/VIP821

Features

• Indoor/ Outdoor use

• High Impact carbonate HousingPoly

•- OmniDirectional Mounting Base

•- Builtin Microphone

•d SIP & Multicast Enable

•Power over Ethernet (PoE) 802.3af and

802.3at mpatibl(PoE+) coe

•R emote Management & Monitoring

D/ Wt imensions eigh

•” 11.75H x 10.0” Wx 11.0” D(29.8cm H x

25.4cm W x 27.9cm D)

• 4.3 lbs. (1.95 kg)

Audio Codecs

•LL G.722, G.711 (uaw, aaw)

Frequency Response

•z 350 Hz to 7kH

Audio Dispersion

•l 120° Horizonta

• 90° Vertical

Nominal Power Requirements

IEEE PoE) 802.3af ( Class 3

IEEE 802.3at (PoE+) Class 4

These products are intended for use with a UL

Listed power source marked “Class 2” or “LPS”

ratedcdc(PoEd 24 V, or 48 V ).

PoE and all interconnected ITE are intended for

intra-. building

Environment

Temperature: - 20° 0 to +5° C

Humidity:0 ond - 95% non-censing
