1 947801

Issue 3

V-0A, VIP-160A- IP16V4

IP TALKBACK CEILING SPEAKER 8”

INTRODUCTION

The VIP-160A and VIP-160A- IP Talkback V48”

Ceiling Speakers enable handsfree talkback access

to a single location over an IP-based LAN/WAN.

The VIP-160A levels are adjusted electrically via

software during setup. A call switch input is

provided for call initiation. Power is provided to the

VIP-160A via a Power over Ethernet (PoE) switch

meeting the 802.3af specication.The VIP-160A

and VIP-160A-V4 are identical in t, form and

function.

SPECIFICATIONS

Access Methods

• SIP enabled telephone system –

• PBX, FXO Port w/Valcom Station Port Gateway

• POTS phone set w/Valcom Station Port Gateway

• PBX, FXS Port w/Valcom Trunk Port Gateway

• Valcom M Cast Page Group

Features

• Full Duplex Communication

• Ambient Noise Adjustment

• 802.3af compliant

• High Eiciency Class-D Amplier ff

INSTALLATION

FCC Information

This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when

the equipment is operated in a commercial

environment. This equipment generates, uses

and can radiate radio frequency energy and if

not installed and used in accordance with the

instruction manual, may cause harmful

interference to radio communications.

Operation of this equipment in a residential area

may cause harmful interference in which case

the user will be required to correct the

interference at his own expense.

DIMENSIONS/WEIGHT

•.0Dia 3.8 13” x ” D

(33.0cm Dia. cm D) x 9.7

•Weight: 2.5 lbs (1.13 kg)

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

Precautionary Designations

CAUTION: To reduce the risk of electric shock,

Do not remove cover.

No user serviceable parts inside.

Refer servicing to qualied service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.
