SALUS Controls is a member of the Computime Group

Maintaining a policy of continuous product development SALUS

Controls plc reserves the right to change specications, design and

materials of products listed in this brochure without prior notice.

SALUS Controls plc,

Units 8-10,

Northeld Business Park,

Forge Way, Parkgate

Rotherham, S60 1SD

United Kingdom

SALUS Controls GmbH,

Dieselstrasse 34,

63165 Mühlheim am Main,

Germany

Quick Guide

UK: [email protected]

DE / NL: [email protected]

PL: [email protected]om

FR: [email protected]

RO: tehnic@saluscontrols.ro

DK: Suppor[email protected]

V01

11/2025

www.saluscontrols.com

RT320BT

WIRED BATTERY THERMOSTAT

2 x Screws2 x Wall anchors

MULTILANGUAGE

MANUAL

This product complies with the essential requirements and other relevant

provisions of Directives: 2015/863/EU, 2014/53/EU The full text of the EU

Declaration of Conformity is available at the following internet address:

www.saluslegal.com.

Product Compliance

Introduction

The thermostatRT320BT starts in manual mode. Use Bluetooth mode to

customize settings and create your schedule. The thermostat is designed to

regulate the temperature of heating or cooling systems. It operates on 4 x

AAA, 1.5V alkaline batteries, which must be inserted into the compartment

behind the removable wall plate. Rechargeable batteries are not supported.

Buttons description

Icons description

Use in accordance to national and EU regulations. Use the device as intended,

keeping it in dry condition. Product for indoor use only. Installation must

be carried out by a qualied person in accordance to national and EU

regulations.

Safety Information

1. Room/Setpoint temperature

2. Battery indicator

3. RF icon (only for RF version)

4. Bluetooth icon

5. Heating mode

6. Cooling mode

7. Frost protection

8. Schedule mode

9. Manual mode

10.Temperature scale in

degrees Celsius

RT320BT

Thermostat

1

56

10

4

3

2

7

8

9

MENU

Press for 5s- Enters the setting Heating or Cooling mode.

Press for 10s- enters the installer Mode. Short press to switch modes

(auto, manual, frost) toggle to next mode.

If you're inside a settings screen and press the 'Menu' button, you'll

return to the previous step without saving.

MINUS

Decrease parameter value/moving on the menu in ‘DOWN’ direction

PLUS

Increase parameter value/moving on the menu in ‘UP’ direction

OK/Validation

Conrms setting or selection

Box content

Short press the Menu button to

switch between the thermostat

modes: Schedule, Manual and

Frost protection.

1

2

Schedule mode activeManual mode ashing

Short press the Menu button to

go to the next mode. Or wait for

3 sec and the existing mode is

saved (icon will be solid after 3 sec).

Short press the Menu button to

go to the next mode. Or wait for

3 sec and the existing mode is saved

(icon will be solid after 3 sec).

3

4

Frost protection ashingSchedule mode ashing

The modes are cyclic.

Thermostat modes

Back plate access & wiring

NO

COM

230V

50Hz

3(1)A

1

Reset / Reboot button

4 x AAA battery slots

2

Loosen the screw.

Do not remove it.

Gently lift the back plate from the

thermostat body to get access.

NO- Normal Open Terminal (volt-free contact)

COM- Common Terminal (volt-free contact)

3

First power-up

1

The thermostat will

display all icons for 2 seconds.

2

Thermostat will display

main rmware.

3

Then it will display

Bluetooth rmware version.

4

The thermostat will

go to the Home screen.

Note: Make sure that the backlight is on before attempting

to operate the thermostat. First press to turn the display on, then

proceed with other button operations.

4 x AAA Alkaline Batteries

Quick

guide

Important: Schedule settings can only be congured via the

thermostat’s Bluetooth function.
