Gigabit Hardened Media Converter
Quick Start Guide
This quick start guide describes how to install and use the Gigabit hardened
media converter. This is the media converter of choice for harsh
environments constrained by space.
Physical Description
The Terminal Block and Power inputs
Power Input Assignment
Power3 12VDC DC Jack
＋
12-48VDC
Power2
－
Power Ground
＋
12-48VDC
Power1
－
Power Ground
Earth Ground
Terminal Block
Relay Alarm Assignment
FAULT
*Relay warning signal disable for following:
The relay contact closes if Power1 and
Power2 are both failed but Power3 on.
The relay contact closes if Power3 is failed
but Power1 and Power2 are both on.
yDC Terminal Block Power Inputs: There are two pairs of power inputs
can be used to power up this media converter.
yDC JACK Power input: 12VDC.
