Gigabit Ethernet Media Converter
Quick Start Guide
This quick start guide describes how to install and use the Gigabit Ethernet media
converter. The converter introduced here provides one channel media conversion
solution.
Physical Description
Product Overview
This Gigabit Ethernet media converter is a plug-and-play device. Connect the supplied
AC to DC power adaptor to the receptacle on the rear panel of the Gigabit Ethernet
media converter, and then attach the plug into a standard AC outlet with a voltage range
from 100 to 240V AC.
DIP Switch
DIP
switch
Up (Default Setting) Down
Left-hand
side
The fiber port auto detects
duplex mode
Force the fiber port to full
duplex mode
Right-hand
side
Disable LFPT Enable LFPT LFPT:
link-fault-pass-through
function
<Note> Power must be on/off after re-setting LFPT function.
The 1000Base-T and 1000Base-SX/LX Connectors
The 1000Base-T Connections
The following lists the pinouts of
1000Base-T port.
The 1000Base-SX/LX Connections
The SFP socket for Gigabit fiber optic
expansion.
User’s Manual 1
