Introduction
1.1 DESCRIPTION
• This electronic beater-mixer is an appliance for professional
use in bakery-patisserie and in the kitchen designed for kneading,
mixing and whipping all kinds of food products. Version A (with the
accessory drive hub) adapted for in the kitchen allows accessory
machines to be driven.
A Stainless steel bowl, 9.9 litre capacity
B Removable safety guard
C Planetary gear
D H12 type accessory socket
E Head
F Top cover
G Control panel
Contents
• There are 3 standard tools available:
A A spiral hook for kneading dough
B A paddle for mixing
C A whisk for emulsifying
1 XBE10 GB 10 2023
10/2023
GB
Introduction 1
Installation 1
Use, safety 3
Cleaning, hygiene 5
Fault nding 5
Maintenance 6
Conformity with regulations 8
This document is to be used in conjunction with the original manufacturer’s manual.
The symbols correspond with the numbered drawings of the original manual.
H Frame
I Bowl cradle
J Legs
1.1a
1.1b
• Optional equipment:
- Accessory machines: vegetable preparation machines, mincers,
etc. (see § 3.6).
The reference language for these instructions is French.
Introduction
The User Manual contains useful information for the user on how
to work correctly and in complete safety, and is designed to make it
easier to use the machine (called «machine» or «appliance» below).
What follows is in no case intended to be a long list of warnings and
constraints, but rather a series of instructions meant to improve the
service provided by the machine in every respect, and particularly
to avoid a series of injuries or damage to equipment that might
result from inappropriate procedures for use and management.
It is essential that all the people responsible for transporting, ins-
talling, commissioning, using, maintaining, repairing or dismantling
the machine should consult this manual and read it carefully be-
fore proceeding with the various operations, in order to avoid any
incorrect or inappropriate handling that might be result in damage
to the machine or put people’s safety at risk.
It is just as important that the Manual should always be available
to the operator and it should be kept carefully where the machine
is used ready for easy and immediate consultation in case of any
doubt, or in any case, whenever the need arises.
If after reading the Manual, there are still any doubts concerning
how to use the machine, please do not hesitate to contact the
Manufacturer or approved After Sales Service provider, who is
constantly available to ensure quick and careful service for im-
proved machine operation and optimum eciency.
Note that the safety, hygiene and environmental protection stan-
dards currently applicable in the country where the machine is
installed must always be applied during all phases of machine
operation. Consequently it is the user’s responsibility to ensure
that the machine is operated and used solely under the optimum
safety conditions laid down for people, animals and property.
Installation
ATTENTION!!
Machine storage: -25°C to +50°C
Ambient temperature for operation: +4°C to +40°C
This machine is for professional use and must be used by sta trained to use, clean and maintain it, in terms or reliability and safety.
Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard
EN 12464-1)
When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the
lower limbs.
The machine is not designed for use in explosive atmospheres.
2.2 LOCATION
• The beater mixer must be tted on a support that is perfectly
stable and horizontal, between 400 and 700 mm high and not
resonant (e.g. a unit, table, etc.).
• Check the direction of rotation
- Of the planetary gear, anti-clockwise (See arrow on head).
- Or of the tool, in a clockwise direction .
To change the direction of rotation, see § 5.2
2.1 DIMENSIONS - WEIGHT (for information only)
- Gross weight packaged : 58 Kg
- Net weight with equipment : 37 Kg
- Dimensions of packaging : 650 x 480 x 800 mm
- Overall dimensions : 601 x 454 x 656 mm
• Motor characteristics :
• This mixer-whisk is to be supplied with single-phase current.
• Provide an accessible standardized wall outlet with 2 poles +
ground, rated at 16A in accordance with IEC60309, and a cor-
responding waterproof plug to be installed on the power cord.
Supply Nominal Frequency Current Electrical
voltage. (V) output (W) (Hz) (A) cons..(Kw/h)
230 750 50/60 4,3 0,8
115 750 50/60 8,6 0,8
2.3
2.1
The machine must be earthed
In certain circumstances depending on the sensitivity of the
protective cut-outs, it may be necessary to install SI-type
(super immunity) devices to prevent untimely triggering.
Note: The machine can only be used on TN (earthing
to neutral) and TT (earthed neutral) type supplies.
Where a machine has to be installed on an IT (impeding
or isolated neutral) supply, there is a solution which
consists of inserting an isolating transformer and locally putting
on the machine on TN or TT supply.
• Warning for the installer:
This electronic whisk is tted with a lter which sends any in-
terference from the mains to earth without going through the
variator. To work properly, the appliance earth connection must
be sound otherwise the interference may go through the variator
and damage it.
NO EARTH = NO PROTECTION = RISK OF BREAKDOWN
Note: The earth values are dened according to the
residual dierential current. Non-compliance with these
instructions may result in invalidation of the warranty.
To PAT test the Electrolux Range of Food Preparation Equipment,
the PCB board needs to be disconnected before any test is done.
This is due to the fact that the boards are tted with a grounding
diode that can give incorrect result during such a test. Also on a
standard appliance a ash test of 25 amps and up to 3000v is
used but, as you would expect, to use this on equipment, which
has a printed circuit, board would be quite destructive to that
board. We would recommend the use of a PAT tester approved
for computer systems which use a lower rate of amps.
The appliance is perfectly safe and is CE certicated. There are
two ways to get overcome this problem.
· Disconnect the board as instructed and test using test for PC’s,
· Or install the mixer on a fused spur (no plug) as this takes it
away from being a portable appliance and the PAT test is then
not needed.
ATTENTION!!
Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised
person (see current standards and legislation in the country of installation).
If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than those
of the machine.
Do not use multiple plugs
The AC power supply to the machine must comply with the following conditions (EN60204-1);
- Maximum voltage variation: ±10%
- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods
ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard
requirements in the country where used.
- Check that the electric mains voltage and the value shown on the specication plate.
- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using a
circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and machine
specications
ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and
connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC
60204-1) with the use of protection devices for automatic shut-o of power in the event of an insulation fault with a TN or
TT, system, or for the IT system, with the use of a permanent insulation or dierentials controller for automatic shut-o.
The requirements of IEC 60364-4-41, 413.1 must apply for this protection.
For example: in a TN or TT system, a dierential circuit breaker must be installed upline of the power supply, with a suitable
power cut-o (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.
ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-
dents due to direct or indirect contacts.
2.3 ELECTRICAL CONNECTION
XBE10 GB 10 2023 2
ATTENTION!!
Clean the machine properly prior to its rst use
Never introduce the hand into the work zone when the machine is operating: risk of injury. Neutralising or modifying the safety
systems is formally prohibited: Risk of permanent injury!!!!
Check that the safety devices operate correctly each time before using (see paragraph on «safety system adjustments»).
Never put a hand, a hard or frozen object in the appliance
For health and safety reasons, always use a washable or disposable strong head covering that covers the hair completely.
Use, Safety
a) Operation:
- Select the speed with button B or G and then press D. The
motor starts after one second and gradually accelerates up to
the displayed speed.
b) Speed variation:
- Use buttons B or G, D showing the status in the speed range.
c) Timed operation:
- Use buttons C or F, E showing the time selected then press H.
Note:
- To change the time being counted down, press key
A and then change with keys C or F and pick up the
cycle by pressing key H.
- The time selected at the start of the cycle is kept in
memory.
- To stop denitively a cycle in progress, press key A twice.
d) Continuous operation:
1- Select “——” on E by pressing and holding down key C.
2- Start by pressing key H.
3- Stop by pressing key A.
3.1 OPERATION, SAFETY
The user’s safety is ensured by:
- The protective screen which means that the tool is kept a
standard distance away and stops the motor when it is raised.
- The beater only starting when the cradle is in the work position
and the protective screen lowered.
- The beater stopping in less than 3 seconds whatever the speed.
- A voltage loss system which requires pressing the ON button
to restart.
- Protection against the motor overheating by the variable speed
drive.
- Observing the instructions in this user manual for using, cleaning
and maintaining the machine.
Control panel:
A OFF button
B Decrease the speed
C Decrease the timer time
D Speed display
E Timer display
F Increase the timer time
G Increase the speed
H ON button
The beater can only be started normally if the bowl-screen
cradle assembly s in the working position the bowl is in position
on the cradle.
Always move the protection screen using the handle
3.1a-b
Any other use than that described in this manual will not be
considered normal by the manufacturer.
Do not use the machine without the bowl.
• Raise the safety guard using the handle, and the cradle will be
lowered automatically.
- Place a tool inside the bowl.
- Position the bowl in front of the cradle and horizontally, insert
the 2 arms of the cradle between the rim of the bowl and the
top of the handles. The bowl is thus automatically centred on
the cradle and rests on the rim.
Note : Do not insert the two cradle arms under the bowl
handles.
- Push the tool into the tool holder spindle, then turn it anticlockwise
to lock it in position.
- Push the safety guard back by means of the handle, and the
bowl will be automatically locked into position.
Note: If the bowl is not tted correctly, it will not be
possible to close the safety guard completely. Do not
force, and ensure the bowl is correctly positioned by
pushing it right back.
- Press the START button, set the speed variation knob to the
chosen speed and turn the optional timer knob (see § 3.1).
3.2 FITTING THE BOWL AND TOOLS
3.2a
3.2b
3.2c
3.2d
3.2a
§5.3
3 XBE10 GB 09 2021
Product specificaties
| Merk: | Dito Sama |
| Categorie: | Niet gecategoriseerd |
| Model: | 600143 |
Heb je hulp nodig?
Als je hulp nodig hebt met Dito Sama 600143 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Niet gecategoriseerd Dito Sama
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
Handleiding Niet gecategoriseerd
- C2G
- Thomson
- Southwire
- Unicol
- Walrus Audio
- Starlyf
- Wago
- Continental Edison
- Industrial Music Electronics
- MXL
- Netsys
- NZR
- Exakta
- CradlePoint
- TTM
Nieuwste handleidingen voor Niet gecategoriseerd
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
