Pagina 1/5
GB
Se reporter aux dessins numérotés correspondant aux numéros des
paragraphes de la notice d’instructions
Presentation 1
Installation 1
Use and safety 2
Cleaning and hygiene 3
Operating incidents 4
Maintenance 4
Conformity with regulations 5
Sommaire
Presentation
Never place the peeling machine in a sink (risk of water leaking
into the motor).
1
T8E GB 09 2016
2.2
2.1
1.1
1.1 DESCRIPTION
This 8kg peeling machine is used essentially for vegetables
to be peeled or for spin-drying vegetables, depending on the
equipment being used.
There is a T8E «mussels» version :
- Motor 1000 rpm – «Special mussel» bowl and plate
E Waste water evacuation
F Partition
G Stainless steel ferrule
H Electric controls
I Bottom
Installation
A Water inlet (clip-on
shower head)
B Removable cover
C Removable bowl
D Filter case (receiving
optional lter)
2. (for information 1 DIMENSIONS AND WEIGHT
only)
• Gross weight packed with abrasive plate: 26,5 kg
• Net weight: 23,5 kg
- Packed sizes : 450 x 480 x 695 mm
- Overall machine dimensions : 422 x 390 x 675 mm
2.2 LOCATION
• The peeling machine requires:
- Connection to the cold water system with a nearby shuto tap
(see § 2.3)
- A large enough drain to the main drain (see § 2.4)
- An electric power supply (see § 2.5)
• It can be mounted:
- On a totally stable and horizontal non-resonating support (table,
cabinet, sink top) with a height included between 500 and 900
mm.
Note: In this case, the peeling machine can be removed easily
after disconnecting the power outlet and the exible water supply
pipe or unclipping the water inlet (shower head) from the cover.
2.3 CONNECTION TO THE WATER SYSTEM
• The peeling machine operates at network pressure and at
low water ow rate.
• In conformity with the sanitary regulations, the machine water
inlet is above the overow level at a standardized distance (spill-
over device).
• The machine is supplied with a 1 m long exible hose having
a 1/2 female connection mating with the shuto tap.
• The clip-on water inlet of the cover means that the machine
can be removed without needing to touch the connecting pipe.
Note: If the peeling machine has to be moved regularly, provide
a connecting pipe equipped with quick couplings.
2.4 WASTE WATER DRAIN AND WASTE
SEPARATION
• Waste separation is necessary, depending on the size of such
waste (pieces of peel, skin, starch, foam, soil) depending on the
equipment used (see § 3.2)
• Some installations have starch decanting tanks to which connec-
tion can be made directly. For other installations, we advise a
lter mounted on the peeling machine to prevent clogging and
bad smells.
• The machine is provided with a drain exible hose 0.7 m long,
not assembled.
- Screw on the exible hose, LH thread, counter-clockwise
into coupling E.
Recommendations:
To drain o the waste water correctly, avoid:
- Vertical falls opening onto a manhole (causing foam to form),
- Abrupt bends,
- Flattened, deformed or shrunken pipes,
- Counter-slopes or excessively shallow slopes
06/2024
The «mussels» version cannot be used to peel potatoes, even
with an abrasive plate.
2.2b
Introduction
The User Manual contains useful information for the user on how
to work correctly and in complete safety, and is designed to make
it easier to use the machine (called «machine» or «appliance»
below).
What follows is in no case intended to be a long list of warnings and
constraints, but rather a series of instructions meant to improve the
service provided by the machine in every respect, and particularly
to avoid a series of injuries or damage to equipment that might
result from inappropriate procedures for use and management.
It is essential that all the people responsible for transporting,
installing, commissioning, using, maintaining, repairing or dis-
mantling the machine should consult this manual and read it
carefully before proceeding with the various operations, in order
to avoid any incorrect or inappropriate handling that might be
result in damage to the machine or put people’s safety at risk.
It is just as important that the Manual should always be available
to the operator and it should be kept carefully where the machine
is used ready for easy and immediate consultation in case of any
doubt, or in any case, whenever the need arises.
If after reading the Manual, there are still any doubts concerning
how to use the machine, please do not hesitate to contact the
Manufacturer or approved After Sales Service provider, who is
constantly available to ensure quick and careful service for im-
proved machine operation and optimum eciency.
Note that the safety, hygiene and environmental protection stan-
dards currently applicable in the country where the machine is
installed must always be applied during all phases of machine
operation. Consequently it is the user’s responsibility to ensure
that the machine is operated and used solely under the optimum
safety conditions laid down for people, animals and property.
The reference language for these instructions is French.
2.5 ELECTRICAL CONNECTIONS
ATTENTION!!
Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised
person (see current standards and legislation in the country of installation).
If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than
those of the machine.
Do not use multiple plugs
The AC power supply to the machine must comply with the following conditions (EN60204-1);
- Maximum voltage variation: ±10%
- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods
ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard
requirements in the country where used.
- Check that the electric mains voltage, the value shown on the specication plate.
- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using
a circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and
machine specications .
ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and
connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1
(IEC 60204-1) with the use of protection devices for automatic shut-o of power in the event of an insulation fault with
a TN or TT, system, or for the IT system, with the use of a permanent insulation or dierentials controller for automatic
shut-o. The requirements of IEC 60364-4-41, 413.1 must apply for this protection.
For example: in a TN or TT system, a dierential circuit breaker must be installed upline of the power supply, with a
suitable power cut-o (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.
ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-
dents due to direct or indirect contacts.
Grounding is mandatory
The machine is supplied with single-phase power by a 2-pole +
ground molded plug. Provide an accessible standardized wall
outlet with 2 poles + ground, rated at 10/16A in accordance with
IEC60309, and a corresponding waterproof plug to be installed
on the power cord.
• Motor characteristics:
power Rated Frequency Current Electrical Speed
Supply(V) Power(W) (Hz) (A) Consu(kWh) rpm
230/240 370 50 2,8 0,54 1500
115 370 60 5,5 0,54 1500
230/240 250 50 2 0,47 1000
Special mussels
To PAT test the Electrolux Range of Food Preparation Equipment,
the PCB board needs to be disconnected before any test is done.
This is due to the fact that the boards are tted with a grounding
diode that can give incorrect result during such a test. Also on a
standard appliance a ash test of 25 amps and up to 3000v is
used but, as you would expect, to use this on equipment, which
has a printed circuit, board would be quite destructive to that
board. We would recommend the use of a PAT tester approved
for computer systems which use a lower rate of amps.
The appliance is perfectly safe and is CE certicated. There are
two ways to get overcome this problem.
· Disconnect the board as instructed and test using test for PC’s,
· Or install the mixer on a fused spur (no plug) as this takes it
away from being a portable appliance and the PAT test is then
not needed.
3.1
Use and Safety
3.1 OPERATION - SAFETY
• The safety of the user is ensured by:
- The need to press the ON pushbutton after a stoppage (“no
voltage” device)
- Compliance with the instructions of this manual for use, cleaning
and maintenance of the machine.
• Control box
I ON pushbutton
O OFF pushbutton
• An adjustable time-lag relay in the machine ensures the ope-
rating cycle (preset to 1minute 30’’).
Time lag relay adjustment:
- Turn the machine over.
- Remove the round rubber cover.
- Using a screwdriver, set the desired time (as a percentage)
E.g.:
3 = 3 min.
2,5 = 2 min. 30»
2 = 2 min.
1,5 = 1mn30’’ (standard adjustment)
a) Startup:
- Press the ON button to begin a 1-min30’’. cycle.
- Automatic stoppage at cycle end.
d) Stoppage
- The O button stops the machine in its operation.
- An impulse on I engages another 1-minute 30’’ cycle.
Any other use than that described in this manual will not be
considered normal by the manufacturer.
2
T8E GB 06 2024
3.2a
3.2b
2.2
3.4b
3.4a
3.2 VARIOUS EQUIPMENT
• ABRASIVE PLATE
- To peel ne-skin vegetables (potatoes, new carrots, salsify).
- The skin wears on contact with the abrasive grain.
- Filter recommended for intensive use or for small-section drain
(to be drained every peeling cycles).
• SPIN-DRYING BASKET: as an option, used for washing and
spin-drying salad, parsley and various aromatic herbs.
3.3 CAPACITIES (FOR INFORMATION ONLY):
• Nominal load per operation:
- Potato peeling (kg): 8
- Salad spin-drying: approximately 700g
parsley approximately 500 g.
3.4 EQUIPMENT STARTUP AND PROCEDURES
- Fit the lter into housing D (see 2.2)
- Place tank C on base F, locking it by turning it clockwise
- Then place the abrasive plate on the drive shaft. Turn the tray
by hand to lower it onto its drive pin.
• With the vegetables loaded, t the cover, locking it by turning it
(clockwise direction ). If the shower head is not on the cover,
clip it in place.
The peeling machine is ready to operate.
- Scraping mussels: 7/8 Kg according to size
•
Indicative outputs (kg/h):
- Potato peeling : 130 kg/h
Check that the plate is correctly positioned. (tray fully
horizontal)
3.6 RECOMMENDATIONS FOR USE
• For peeling vegetables:
- There is no need to wash vegetables before peeling them.
- Do not work with too small a quantity.
- Peel vegetables of the same size
- Cut vegetables that are too long (salsify), protuberances, carrot
forks.
- Peeling time: 2 min. average depending on type of vege-
tables.
Do not overload - Do not pack the products down. Any over-
loading will be detrimental to the quality and speed of work.
Be sure to empty the lter at the end of peeling.
• Loading
- Add a load of vegetables and close the cover.
Note: The minimum product loading level must not exceed the
edge of the cylinder.
- Open the water inlet tap, making sure that the shower head is
clipped on to the cover.
- Start up.
• Unloading
- Close the water inlet tap.
- Unlock the cover and remove it.
- The cover shower head can be unclipped for cleaning the base.
- Unlock the cylinder, which can be transported with its content
and the plate.
3.5 PROCEDURE FOR PEELING, BRUSHING AND WASHING
4.1
Cleaning and hygiene
4.1 AFTER USE
Separate all removable parts:
- Tank, cover, abrasive plate for soaking or washing in a ma-
chine.
- For the mussels bowl and plate, it is strongly recommended
to brush before machine washing in order to eliminate residue
from the previous mussel cleaning session.
- It is mandatory to empty the lter basket and clean it under the
tap.
- Clean the outside of the machine using a damp sponge.
Note: Do not use abrasive detergent which can score the surfaces
or chlorine-based detergents which will tarnish the aluminum or
cause the plastics to fracture.
Do not wash the machine with a high pressure jet.
3
T8E GB 12 05
Product specificaties
| Merk: | Dito Sama |
| Categorie: | Niet gecategoriseerd |
| Model: | 603506 |
Heb je hulp nodig?
Als je hulp nodig hebt met Dito Sama 603506 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Niet gecategoriseerd Dito Sama
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
Handleiding Niet gecategoriseerd
- Livarno
- Black Lion Audio
- Perel
- Elkay
- AVM
- Jupiter
- Minox
- Onvian
- ProFlo
- Farberware
- Pro-User
- Twelve South
- SoundLAB
- Ultimate Speed
- Caretero
Nieuwste handleidingen voor Niet gecategoriseerd
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
