AXGM-17

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 12/29/23 INSTAXGM-17

ATTENTION: With the key out of the

ignition, disconnect the negative battery

terminal before installing this product.

Ensure that all installation connections,

especially the air bag indicator lights, are

plugged in before reconnecting the battery

or cycling the ignition to test this product.

NOTE: Refer also to the instructions included

with the aftermarket accessory before

installing this device.

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Cutting tool • Tape • Crimping tool

• Connectors (i.e. butt-connectors, bell caps, etc.)

TABLE OF CONTENTS

Connections

LD-GMOS-LAN-26 harness ...............................2

LD-GMOS-212 harness.......................................3

Brown Wire (Mute/OnStar

®

)

Installation .............................................................4

Programming .........................................................4

Adjustments

Chime Level.......................................................5

OnStar

®

Level Adjustment ....................................5

GM Chime Interface 2004-2007

• Designed for non-amplified models with OnStar

®

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (Retained Accessory Power) feature

• Retains OnStar

®

/OE Bluetooth

®

• Adjustable volume for OnStar

®

• Retains balance and fade

• Micro-B USB updatable

• AXGM-17 interface • LD-GMOS-LAN-26 harness

• LD-GMOS-212 harness • LD-2NAV harness

APPLICATIONS

Saturn

Ion ...................................................................................................2004-2007

Vue ..................................................................................................2004-2007

Visit AxxessInterfaces.com for more detailed information

about the product and up-to-date vehicle specific applications
