AXAC-CH8

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2026 METRA ELECTRONICS CORPORATION REV. 2/9/26 INSTAXAC-CH8

INTERFACE FEATURES

TABLE OF CONTENTS

Introduction ...........................................................2

Features cont. ........................................................2

Required tools & items ..........................................2

Configuration .....................................................2-4

Connections ............................................................5

Rebooting the Radio .............................................5

Installation .............................................................6

Harness Installation

LD-AXAC-CH7 & LD-AC-CH8 ................................7

Programming .........................................................8

• Retains the factory backup camera while adding up to three

additional CAN-activated cameras (4 total camera inputs)

• Includes AXAC camera interface and vehicle-specific harness

• Programmable 12-volt, 5-amp switched output (configured via the

Axxess Updater program)

• Reverse trigger generated through CAN bus communication

• AXAC-CH8 interface

• AXAC-CH8 interface harness (LD-AXAC-CH7)

• AXAC-CH8 vehicle harness (LD-AC-CH8)

For vehicles equipped with Uconnect

®

and 12”/12.3” screen

Camera Interface with Pre-Wired Harness

Fits Select Chrysler Models 2023-UP

APPLICATIONS

Jeep Wrangler JL with Uconnect

®

(12.3 inch touchscreen) .......2024-Up

Ram 1500 DT with Uconnect

®

(12.0 inch touchscreen) ..............2023-Up

Visit AxxessInterfaces.com for more detailed information

about the product and up-to-date vehicle specific applications

INTERFACE COMPONENTS

www.Metraonline.com

MetraOnline.com may be used to assist

with dash assembly instructions. Simply

enter your Year, Make, Model vehicle

into the vehicle fit guide and look for the

Dash Kit Installation Instructions.

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal before

installing this product. Ensure that all installation

connections, especially the air bag indicator lights,

are plugged in before reconnecting the battery or

cycling the ignition to test this product.

NOTE:Refer also to the instructions included

with the aftermarket radio.

Continued on the next page
