Camera Retention Harness Fits Select GM Models 2008-2018Camera Retention Harness Fits Select GM Models 2008-2018
APPLICATIONS
INSTALLATION INSTRUCTIONS
INTERFACE COMPONENTS
FEATURES
Cadillac
CTS .........................................2008-2014
CTS-V .....................................2008-2014
Escalade (NAV) .....................2012-2014
Escalade ..............................2010-2014
Chevrolet
Avalanche (NAV)..................2012-2013
Camaro .................................2010-2015
Cheyenne (NAV) ..................2012-2014
Cruze ....................................2011-2015
Equinox (Color Screen) ........2012-2018
Equinox (Monochrome) ......2010-2018
Chevrolet cont.
Express (NAV) ......................2008-2014
Malibu limited ......................2016
Malibu (Manual Climate) .....2013-2015
Silverado (NAV) ...................2012-2013
Suburban (NAV) ...................2012-2014
Tahoe (NAV) .........................2012-2014
Trax .......................................2015-2016
GMC
Sierra (Nav) ..........................2012-2013
Terrain ...................................2010-2017
Yukon (NAV) .........................2012-2014
From the LD-BACKUPCAM-2 harness
• Connect the Yellow RCA to the backup camera input of the aftermarket radio
•
Connect the Blue/Pink wire to the vehicle speed sense wire of the aftermarket radio
• LD-BACKUPCAM-2 harness
• Retains factory back up camera to an aftermarket radio
•
For use in 44-way connector vehicles that have OEM installed backup camera
