METRA. The World’s best kits.™metraonline.com1-800-221-0932
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Installation Instructions for AXVRI
REV. 2/3/2020 INSTAXVRI
AXVRI
Voltage Retention Interface
CONNECTIONS TO BE MADE
From the 8-pin harness to the vehicle-side harness:
• Connect the (3) Black wires to the ground wire.
• Connect the Yellow fused wire to the battery wire.
• Connect the Red fused wire to the accessory wire.
From the 6-pin harness to the aftermarket radio:
• Connect the (2) Black/White wires together, then connect them to
the ground wire.
• Connect the (2) Yellow/White wires together, then connect them to the
battery wire.
• Connect the (2) Red/White wires together, then connect them to the
accessory wire.
Note: Each individual line is rated at 5-amps per line (10-amps
combined total). If each line is going to be used for separate sources--
or the current will surpass 10-amps--please use a relay, Metra part
number E-123 to increase current.
Caution: Metra recommends disconnecting the negative battery terminal before beginning
any installation. All accessories, switches, and especially air bag indicator lights must be
plugged in before reconnecting the battery or cycling the ignition.
*Note: Refer also to the instructions included with the aftermarket radio.
INTERFACE COMPONENTS
• AXVRI Interface • 8-pin harness with stripped leads and fuses
• 6-pin harness with stripped leads
TOOLS REQUIRED
• Cutting tool • Tape • Crimping tool
• Connectors (i.e. butt-connectors, bell caps, etc.)
FEATURES
• Provides 12-volt output when voltage drops below 7-volts
• Designed for vehicles that drop voltage while stopped
• Fuses included for safety
• Provides accessory power (12-volt 10-amp)
