1.Pulloutthewiresandgroundingwirefromthepost.Makewireconnections

usingthewirenuts:

---Theblackwirefromthefixturetotheblackwirefromthepost.

---Thewhitewirefromthefixturetothewhitewirefromthepost.

---Thegroundingwirefromthefixturetothegroundingwirefromthepost.

Carefullytuckthewiresbackintothepost.

060622

ASSEMBLYANDINSTALLATION

INSTRUCTIONS

WARNING:BESURETOSHUTOFFPOWERATTHEMAINFUSEORCIRCUIT

BREAKERBOXBEFOREINSTALLINGORSERVICINGTHISFIXTURE.

NOTE:Beforeinstalling,consultlocalelectricalcodesforwiringandgroundingrequirements.

OP21505

Ball Nut

Glass Shade

Metal Cover

Post Cap

2. Place the post cap on the post, then secure it with three set screws.

3. Install a bulb (not included). See relamping label atsocket area or packaging

for maximum allowed wattage.

4. Place the glass shade into the metal cover carefully, then attach the metal

cover to the fixture by using two ball nuts.

5

. Turn on the power at the main fuse or circuit breaker box.

Post

Wire nut

Grouding Wire

Set Screw

Fixture Wire

Fixture
