1 947636

CAUTION: To reduce the risk of electric shock,

Do not remove cover.

No user serviceable parts inside.

Refer servicing to qualified service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

ISSUE 1

VIP-9880A

IP FlexHorn with Square Grille

INTRODUCTION

The VIP-9880A IP FlexHorn with grille enables

loudspeaker voice paging anywhere on an

Ethernet network. The VIP-9880A consists of a

high efficiency Class-D Horn and a Network

Interface, allowing stand alone capability when

used with a SIP-enabled telephone system or can

be accessed from a variety of Valcom managed

VoIP products. Power is provided to the

VIP-9880A via a Power over Ethernet (PoE)

switch meeting the 802.3af specication.

SPECIFICATIONS

Access Methods

SIP-enabled telephone system

PBX, FXO Port w/VIP-811

POTS telephone set w/VIP-811

PBX, FXS Port w/VIP-821

Valcom M Cast Page Group

Features

RJ-45 for network connection

Network activity LEDs

Power over Ethernet 802.3af compatible

White painted steel faceplate

Dimensions/Weight

10.75” H x 10.75" W x 4.0" D

(27.3cm H x 27.3cm W x 10.2cm D)

Weight: 3.1 lbs. (1.4 kg)

Nominal Specifications

Input Impedance: 600 Ohms

Input Level: -10dBm

Output Impedance: 600 Ohms

Output Level: -10dBm nominal

Nominal Power Requirements

Via 802.3af (PoE) Ethernet Switch: Class 3

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

Packing List

Precautionary Designations

Qty Item

1 VIP-9880A IP FlexHorn w/Grille

1 VSP Document
