Thank you for choosing SkyRC PC1080 dual channel LiPo charger.

This charger is capable of balance charging 2 packs of 6 cell batteries simultaneously. It is specifically

designed for big battery pack. There are three working modes, fast charge, balance charge and storage .

Master and Slave mode are available, enabling the user to perform synchronous settings for numerous

(synchronize 2 or more) chargers via data cables. In addition, PC1080 has short-circuit, reverse

polarity, and overheat protection to ensure maximum safety.

Power on: connect to the power source and turn on the power switch. A beep sound will be heard, and the LCD

screen will be displayed as below:

Battery connection: Please connect your batteries to PC1080 charger as below:

(Note: Be aware that the Lithium battery to be charged should be 6 cells. Make sure the battery balance lead and

charging lead are connected correspondingly to the charger.)

1)

2)

LiPo FAST CHARGE

2.0A OFF-LINE

Battery Type (LiPo/LiHV)

Charging Current (1.0-20.0A)

Charging modes (fast charge

balance charge & storage)

Synchronous status

(Off, Master, Slave)

-2-

SkyRC PC1080 charger

AC power cord

Synchronous data

connectors

INSTRUCTIONMANUAL

PC1080SK-100124

PRODUCT DESCRIPTION

Handle

LCD Display of Second Channel

LCD Display of First Channel

Control Button

Balance Socket

XT90 Battery Port

Anti-dust Air Intake

FEATURES

Support charging 2 packs of 6s LiPo batteries simultaneously

Support high voltage LiPo (LiHV) battery

Memorizing last charging current

Three working modes: fast charge, balance charge & storage

Master & Slave mode available

Synchronize 2 or more chargers via data cable.

Maximum safety: short circuit protection, reverse polarity protection & over heat protection.

Adjustable charging current

2x16 LCD screen.

Real time charging/ discharging status display

Battery voltage meter

Battery internal resistance meter

Firmware upgrade via USB port

PACKAGE CONTENTS

OPERATION PROCEDURE

Power Switch

PC Link

Data Link

AC Input 110V-240V

Cooling Fan

-1-
