Installation and Operation Manual
Manuel d’installation et d’utilisation
Manual de instalación y operación
Commercial Horizontal Sand Filter
Models: SFHT3461 SFHT3472
SFHT3484 SFHT4272
SFHT42 8 4 S FHT4296
WARNING
FOR YOUR SAFETY – This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed
where such state or local requirements exist. The maintainer must be a professional with sufficient experience in pool equipment installation and maintenance so that all of the instructions
in this manual can be followed exactly. Before installing this product, read and follow all warning notices and instructions that accompany this product. Failure to follow warning notices
and instructions may result in property damage, personal injury, or death. Improper installation and/or operation may void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which may cause serious injury, property damage, or death.
ATTENTION INSTALLER – This manual contains important information about the installation, operation and safe use of this product. This information should be given
to the owner/operator of this equipment.
Page 2
ENGLISH Jandy
®
Commercial Horizontal Sand Filter | Installation & Operation Manual
Table of Contents
EQUIPMENT INFORMATION RECORD
DATE OF INSTALLATION _______________________________________________________________________________
INSTALLER INFORMATION _____________________________________________________________________________
INITIAL PRESSURE GAUGE READING (WITH CLEAR FILTER) ____________________________________________
NOTES _______________________________________________________________________________________________
______________________________________________________________________________________________
Section 1. Important Safety Instructions ......... 3
1.1 Safety Instructions .........................................3
Section 2. Getting Started ................................. 5
2.1 Package Contents ..........................................5
2.2 Purchased Separately ....................................5
2.3 Inspection .......................................................5
2.4 Receiving a Shipment ....................................5
2.5 Damaged Shipment .......................................5
2.6 Specifications and Dimensions ...................... 6
2.7 Equipment Location .......................................8
Section 3. Installation ........................................ 9
3.1 Remove Components From
Shipping Crates/Cartons ................................9
3.2 Position the Tank ............................................9
3.3 Assembly of Grooved Connections (clamps not
included) .......................................................10
3.4 Assembly of Flanged Connections (flanges not
included) .......................................................10
3.5 Weld Solvent PVC Pipe and Fittings ............10
3.6 Remove the Access Hatch ...........................11
3.7 Install Pressure Gauges ............................... 11
3.8 Install Valve Manifold and Supports .............11
Section 4. Start-Up and Operation ................. 12
4.1 Install Media .................................................12
4.2 Check Freeboard ..........................................12
4.3 Reinstall Access Hatch ................................13
4.4 Initial Backwash Cycle .................................13
4.5 Recirculating Pump Requirements ...............14
4.6 Initial Backwash Requirement ...................... 14
4.7 Start the Filter ...............................................14
Section 5. Maintenance ................................... 14
5.1 General Maintenance ...................................15
5.2 Daily Maintenance ........................................15
5.3 Annual Maintenance .....................................15
5.4 Backwashing ................................................15
5.5 Inspection and Service .................................16
5.6 Winterizing ....................................................16
5.7 Head Loss Curve for #20 Silica Sand ..........17
5.8 Differential Pressure .....................................17
Section 6. Troubleshooting .............................17
Section 7. Product Specifications and
Replacement Parts ........................17
7.1 Access Hatch ...............................................18
7.2 External Air Vent ...........................................19
7.3 Pressure Gauge Panel Assembly .................20
7.5 Media Drain .................................................. 22
7.6 Internal Assemblies ...................................... 23
Product specificaties
| Merk: | JANDY |
| Categorie: | Waterfilter |
| Model: | SFHT3484 |
