STEP 1

Determine mounting location and install the mounting bracket with the arrows pointing up with the 5 mm Euro screws provided.

STEP 2

Separate slide by compressing the black release clip.

IMPORTANT:

Before you begin, make sure you familiarize yourself with all the

parts and fully read the instructions.

CUSTOMER SERVICE:

Toll free customer help line available weekdays between 7:00am

and 6:00pm Central Time at 800-463-0660.

TOOLS NECESSARY:

Screw gun or Phillips screwdriver. NOTE: If screw gun has a

clutch, set to lowest setting so as not to over tighten and/or

strip screws.

PARTS IDENTIFICATION:

1Mounting Bracketqty 2

2Pant Rack Slide Coversqty 2

3Pant Rack Cross Memberqty 1

4

Pant Hanger

PPR-1814 qty 9

PPR-2414qty 13

PPR-3014qty 16

55 mm Euro Screw qty 4

6Color coated Pan Head Machine Screwqty 4

PANT RACK SERIES

Installation Instructions

for the PPR-1814, PPR-2414, PPR-3014

6

5

4

3

2

2

1
