7120-01

Install light bulbs (not included) in accordance with the fixture’s

specifications. Do not exceed the recommended maximum wattage.

Carefully remove all contents from the carton. See the

important notes above. Shut off the power at the circuit

breaker and completely remove the old fixture from the

ceiling, including the old crossbar. Remove the crossbar

assembly from the bag. Crossbar (B) contains several

pairs of threaded holes. Find the pair of holes that matches

the spacing of the holes on the junction box and the fixture’s

canopy. Two mounting screws (A) should be attached to

crossbar (B). You may need to tighten nuts (C) to hold these

screws in place. Pull the house wires through the center of

crossbar (B). Place crossbar (B) over the junction box so

that mounting screws (A) are vertical and aligned with

the hole locations on the fixture’s canopy (F). Secure

crossbar (B) to the junction box by tightening the screws.

crossbar

crossbar

There are an 18 inch rod (K), a 12 inch rod (L), and a 6

inch rod (M) included for each fixture. Determine the correct

number of rods needed for proper hanging height. To lengthen

the fixture, add additional rods. If additional rods are needed,

contact the place of purchase to order. To shorten the fixture,

trim the wires to the desired length, leave at least 8 to 10 inches

of wire in addition to the desired length and slide any excess

rods off to discard. Keep in mind that you must use at least the

provided 6 inch rod (M) to hang the fixture. Thread the wires

Push canopy (F) up to the ceiling and tighten the deco nuts (H)

onto the exposed mounting screws (A).

through the rods and pull the wires until taut before

connecting the rods together. Thread bottom rod (M)

onto nipple (N) on the fixture. Thread the nipple of the

top rod onto swivel post (I) of canopy (F). Pull the fixture

wires through the top of the canopy.

SMOOTH
