5620-01
C
D
E
crossbar.
The crossbar (A) has several pairs of threaded holes. Find the pair of holes that matches the spacings on the junction box and your fixture’s
backplate. Two mounting screws (B) should be attached to the crossbar (A). Pull the house wires through the center of the crossbar (A).
Place the crossbar (A) against the junction box so that the mounting screws (B) are aligned with the holes on the fixture’s backplate (E).
Secure the crossbar (A) to the junction box by securely tightening the mounting screws (D).
Attach the fixture’s wires to the power supply wires from the junction box. Connect the black wire with the black( or smooth); the white wrie with
the white (or ribbed); the ground wire with the ground (green or copper). Twist the end of the wire pairs together and twist on a wire connector.
Make sure all twists are in the same direction. If there is no ground wire(green or copper) from the junction box, locate the ground screw (C) on the
crossbar (A) and wrap the fixture’s the ground wire around the green ground screw (C). Use a screwdriver to tighten the ground screw (C) onto the
crossbar. Tuck all wires neatly into the junction box.
Place the fixture’s backplate (E) over mounting screws (D) so that they protrude through the holes on the backplate. Screw deco nuts (B) onto the
junction box. Twist until the backplate of the fixture is snugly against the wall. Install light bulb(s) (not included) in accordance with the fixture’s
specifications. Do not exceed the recommended maximum wattage.
Product specificaties
| Merk: | Forte Lighting |
| Categorie: | Verlichting |
| Model: | 5620-01 |
