5743-01 5743-02 5743-03 5743-04
crossbar.
The crossbar (B) has several pairs of threaded holes. Find the pair of holes that matches the spacings on the junction box and your
fixture’s backplate. Two mounting screws (A) should be attached to the crossbar (B). Pull the house wires through the center of the crossbar (B).
Secure the crossbar (B) to the junction box by securely tightening the mounting screws (A).
Place the fixture’s backplate (D) against the cross bar (B), secure the backplate by tightening screws (G) from the top of the backplate (D). Twist
until the backplate of the fixture is snugly against the wall.
Secure shade (F) onto the socket (E) by screwingsocket ring (H) tightly. Install
light bulb(s) (not included) in accordance with the fixture’s specifications. Do not exceed the recommended maximum wattage.
These instructions are provided for your safety. It is very important to read them carefully and completely before beginning
installation of the lighting fixture.We strongly suggest that all direct-wired fixture be installed by a qualified and licensed
electrician.
W A R N I N G! S H U T POWER OFF AT FUSE OR CIRCUIT BREAKER
BEFORE INSTALLATION
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DIS JONCTEUR.
Attach the fixture’s wires to the power supply wires from the junction box. Connect the black wire with the black( or smooth); the white wrie with
the white (or ribbed); the ground wire with the ground (green or copper). Twist the end of the wire pairs together and twist on a wire connector for
each color pair. Make sure all twists are in the same direction. If there is no ground wire(green or copper) from the junction box, locate a ground
screw (C) on the crossbar (B) and wrap the fixture’s the ground wire around the green ground screw (C). Use a screwdriver to tighten the ground
screw (C) onto the crossbar. Tuck all wires neatly into the junction box.
CLEANING TIPS
Treat the fixture gently! Regular cleaning will reduce the need of deep cleaning. For regular cleaning, turn off the lighting and wipe down
the fixture with a clean lint-free cotton or microfiber cloth. Never spray cleaner directly onto the fixture.
B
A
C
SMOOTH
D
I
H
E
F
G
Product specificaties
| Merk: | Forte Lighting |
| Categorie: | Verlichting |
| Model: | 5743-04 |
