Specificationssubjecttochangewithoutnotice.
Copyright©2009-2016FLIRSystemsInc.Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform.
www.extech.com
4/4/16-R1
Combinesa1000VInsulationTester
Withafull-featuredTrueRMSMultiMeterinasingle,compactinstrument
CATIVInsulationTester/MultiMeter
withWirelessPCInterface
OrderingInformation:
MG300..................CATIVInsulationTester/TrueRMSMultiMeterw/WirelessPCInterface(915MHz)
MG300-NIST........MG300withCertificateofCalibrationTraceabletoNIST
MG302..................CATIVInsulationTester/TrueRMSMultiMeterw/WirelessPCInterface(433MHz)
MG302-NIST........MG302withCertificateofCalibrationTraceabletoNIST
TL805....................DoubleInjectedTestLeads
(NOTE:USA,Mexico,andCanadause915MHzmodelandmajorityofothercountriesuse433MHzmodel)
Features:
•WirelessUSBinterfacetransmitsmeasurementdatatoaPC
•Backlitsuperlargetripledisplay
•125V,250V,500V,and1000Vtestvoltages
•InsulationResistancefrom0.001Mto4000MΩΩ
•Autodischargeofcapacitivevoltage
•LockPowerOnFunctionforhands-freeoperation
•DataHoldandAutoPowerOff
•Min/MaxandRelativemode
•Waterproof(IP67)ruggeddouble-moldeddesign
•CompletewithremotereceiverwithUSBcable,Windows
®
compatible
software,heavydutytestleads,alligatorcliptestlead,TypeKbeadwire
temperatureprobewithadapter,carryingcase,and6xAAbatteries
SpecificationsRangeResolutionAccuracy
InsulationTester
InsulationResistance4M40M400M,4000M0.001M±3%Ω,Ω,ΩΩΩ
InsulationTestVoltages125V,250V,500V,1000V
Multimeter
ACVoltage1000V0.1mV±1%
DCVoltage1000V0.01mV±0.06%
ACCurrent10A0.1µA±1.5%
DCCurrent10A0.01µA±1.0%
Resistance40MΩ0.01Ω±0.3%
Capacitance40mF0.001nF±3.5%
Frequency100MHZ0.001HZ±0.1%
DutyCycle0.1to99.9%0.01±1.2%
Temperature-58to1832°F0.1°F±1%+4.5°F
-50to1000°C0.1°C±1%+2.5°C
4-20mA%-25to125%0.01%
Continuity/DiodeYes
Powersource6xAAbatteries
Dimensions7.8x3.6x1.9”(200x92x50mm)
Weight20.5oz(582g)
Measuretheinsulationresistanceof
transformerwindings
Continuousdatastreamingtoyour
PCinrealtime
OnlyaTrueRMSmetercangiveaccurate
readingsofdistortedwaveforms
ULlistedonMG300only
