Specifications subject to change without notice.
Copyright © 2009-2011 Extech Instruments Corporation. All rights reserved including the right of reproduction in whole or in part in any form.
www.extech.com
8/3/12 - R1
Integrated Non-Contact Voltage Detector
To quickly check for the presence of live wires before testing plus
20A and 200A current ranges
200A AC Clamp Meter + NCV
Ordering Information
MA250........................200A AC Clamp Meter + NCV
MA250-NIST................MA250 with NIST Certificate
Features:
•Built-in non-contact Voltage detector with LED alert
•1.2" (30mm) jaw size for conductors up to 500MCM
•4000 count LCD display
•Multimeter functions include AC/DC Voltage, Resistance,
Capacitance, Frequency, Temperature, Duty Cycle, Diode,
and Continuity
•Relative Mode for Capacitance Zero and Offset Adjustment
•Data Hold freezes reading on display
•Auto Power Off
•Complete with test leads, general purpose Type K bead wire
temperature probe, two AAA batteries, and carrying case
Built-in non-contact Voltage detector with LED alert
Compact size allows measurements in tight locations
SpecificationsRangeMax. ResolutionBasic Accuracy
(% readings+digits)
Display counts4000
AC Current20.00A, 200.0A0.01A±(2.5% + 8d)
AC Voltage4.000V, 40.00V, 400.0V, 600V0.001V±(1.8% + 8d)
DC Voltage400.0mV, 4.000V, 40.00V, 400.0V, 600V0.1mV±(0.8% + 2d)
Resistance400.0ΩΩ, 4.000k, 40.00k, 400.0kΩΩ,
4.000MΩ, 40.00MΩΩ0.1±(0.8% + 2d)
Frequency10Hz to 10kHz0.01Hz±(1.5% + 2d)
Capacitance40.00nF, 400.0nF, 40.00μF, 100.0μF0.01nF±(3.0% + 5d)
Temperature-4 to 1400°F (-20 to 760°C)0.1°±(3% + 9°F/5°C)
Duty Cycle0.5 to 99.0%0.1%±(1.2% + 2d)
DiodeYes
ContinuityYes
Dimensions7.9x2.6x1.5" (200x66x37mm)
Weight7.2oz (205g)
