© MuxLab Inc. 94-000903-A SE-000903-A

2321Rue Cohen, Montreal, Quebec, Canada. H4R 2N7

Tel: (514) 905-0588 Fax: (514) 905-0589

Toll Free (North America): (877) 689-5228

E

-

mail:

info@muxl

ab.com

URL:

www

.muxlab.co

m

Specifications

Environment HDMI 2.0b

Devices

Blu

-

Ray

, projectors, monitors, TV, PC, laptops, servers supporting HDMI.

Transmission

Transparent to the user

.

Bandwidth

300

MHz

Signals

HDMI

2.0b, HDR10, and HDCP 2.2

Connectors

Note: C

ables not include

d.

One (1) HDMI receptacle.

One (1) RJ45S for Cat 5e/6 unshielded or shielded twisted pair.

Two (2) 3.5mm jacks for IR emitter (on TX)/sensor (on RX).

Two (2) 3.5mm jacks for audio insert (on TX)/audio extract (on RX)

One (1) DB9 for the RS232.

Four (4) DI

P Swi

tches for device ID addressing.

Maximum Distance

Based on a maximum length

of 6.6ft (2m) of HDMI cable

per end.

Cat5e/6: 330ft (100m) up to 4K @ 30Hz (4:4:4) and 4K @ 60Hz (4:2:0)

Note: When installed in an electrically noisy environment, an STP cable must be

used. Also, cross-connection reduces the effective distance depending on the

grade of twisted cable used.

Latency

Typical o

ne (1) Frame

(16ms), maximum 2 frames (33ms)

.

Compression Proprietary Compression.

Bandwidth

Up to

500

Mbps

.

Network Requirement

100

0

BaseT

with Jumbo Frame

.

IR Frequency 38 to 56 KHz (IR Emitter and IR Sensor sold separately).

RJ45 Pin Configuration

Reverse Polarity Sensitive.

Use EIA/TIA 568A or 586B

straight-through wiring.

RJ45 Link

Pin 1 (R) Pin 2 (T)

Pin 3 (R) Pin 6 (T)

Pin 4 (R) Pin 5 (T)

Pin 7 (R) Pin 8 (T)

Cable

One (1) Cat 5e/6 or better twisted pair cables required

.

Power Supply This device supports PoE (PD), an external power supply is not included. It is

intended to be powered via a PoE (PSE) Ethernet Switch. If required, an optional

power supply (500993) may be purchased separately.

PoE

IEEE 802.3af

Power Consumption

Transmitter:

6

Watt

Receiver:

6

Watt

Temperature Operating: 0° to 40°C Storage: -20° to 85°C

Humidity: Up to 95% non

-

condensing

Dimensions

4.40

” x

5.0

8

” x

1.00

” (

112

mm

x

12

9

mm

x

25

mm)

Weight

1.

5

lb

s

(0.

68

kg)

Compliance

Regulatory: FCC, CE, RoHS

Flammability: 94V0

Warranty

3

years

Order Information 500759-TX HDMI 4K over IP PoE Transmitter

500759

-

RX

HDMI

4K over IP PoE

Receiver

Accessories

(These items are sold

separately)

500920 16-Port Rackmount Transceiver Chassis

500917 Wall Mount Transceiver Bracket Kit

500990 IR Emitter, and 500991 IR Sensor

500993 Univ. Locking Power Supply 5VDC/2.6A US/UK/EU Blade

HDMI/Dante over IP PoE Extender

500759 TX Dante

Quick Installation Guide

Overview

MuxLab’s HDMI/Dante over IP PoE Transmitter, UHD-4K (model 500759-TX-Dante) delivers

HDMI at up to 4K@30Hz with Dante audio to create an independently distributed AV network.

Hundreds of displays and various video wall configurations are supported, depending on network

bandwidth. Audio can be independently distributed to hundreds of Dante supported audio devices.

Each Transmitter can be connected via Cat5e/6 cable up to 330ft (100m) from an Ethernet Switch.

These units support HDR10 at up to 4K @ 30Hz (4:2:2).

The Transmitter supports PoE (PD) and may be powered by a PoE (PSE) Ethernet Switch. The IR

Emitter and IR Sensor, if required, may be purchased separately for IR based remote control

applications.

For the point-to-multipoint and multipoint-to-multipoint configuration the Ethernet switch must

have Gigabit ports, DHCP server capability, and support IGMP and Jumbo Frames. MuxLab

recommends using the Cisco SG350 series Managed Switches or the SG550X series stackable

version.

Applications

Applications including any audio Dante digital systems in professional and commercial

applications over long distances.

Installation

1.Identify the connectors on the Transmitter as indicated on the product labels, see the above front

and rear product views for further details.

2.Verify that the distance between the HDMI Transmitter is within MuxLab specifications (see

Specifications table for more details).

3.To install the Transmitter:

3a.Connect the Transmitter to the HDMI video source with an HDMI compliant cable.

3b.If the application is point-to-point, then connect one (1) length of Cat 5e/6 (or higher)

grade UTP cable to the RJ45 LINK connector on the Transmitter. If transmitting over

the network, use an Ethernet Switch between Transmitter and Receiver

4.Configuring Dante equipment

4a Use the free Dante Audinate Controller software found on the Audinate website

(https://www.audinate.com/products/software) to manage the connectivity between the

500759 TX Dante and other Dante audio equipment. Both point-to-point and point-to-

multipoint connections are supported.
