2.Quick Setup

After the connection is completed,use a mobile phone or computer to search for the

Wi-Fi SSID on the label at the bottom of the device & enter the corresponding

password to connect to Wi-Fi. Open the mobile phone or computer browser,visit the

192.168.0.1 website,enter the default password on the label at the bottom of the

device,and enter the router management interface.

3.Configure Router Network Mode

Router can configure include DHCP/AP Mode/PPPoE/Static IP, please select one

according to own network environment.

3.1 PPPoE Mode

Fill in the User Name and Password.

3.2 DHCP Mode

The router is default to DHCP (dynamic IP) for internet access.

3.3 AP Mode

The router acts as a bridge in AP mode, and the downstream devices obtain IP

addresses from the upstream gateway of the router to access the internet.

3.4 Static IP Mode

Fill in the IP Address, Subnet Mask, Default Gateway & DNS1 (DNS2 is optional).

4. Configure Wi-Fi information and login password

User can configure Wi-Fi information and login password on the next page,If you

don't want to modify any values, click "Save/Apply" to proceed to the next step.

Modify the wireless SSID, wireless key, and login password according to the user's

wishes.

4.1 Display Modified Data

Display the modified wireless information and login password, and wait for the router

configuration to complete.

4.2 Configuration Status

Display the current configurat

ion status, and user can access the management page

through the "Device Management" link.

When the router is configured for the first time, it will automatically enter the quick

configuration wizard page.

Connect Your Device

Connect via Wi-Fi

Connect via a Network Cable

Connect your device to the

Router's Wi-Fi.

The default Wi-Fi name and

password are printed on

the label on the bottom

of the device.

Connect to ISP Connection Box

Using the included Ethernet cable,

connect the Router’s WAN port to the

Ethernet port on your NBN or UFB

Connection Box.

Connect your PC to the

Router’s LAN1, LAN2,

LAN3 or LAN4 port using

a network cable.

Cable

Cable

LAN

UNI-D1

Power

2.5G WAN

NBN / UFB Box

Wi-Fi 7 BE3600 Mesh

Gigabit Wireless Router

DIR-BE3602
