IMPORTANT! Installation Requirements

• Visit the product page to download the latest rmware, document version,

additional documentation, and conguration tools.

• Read through the Wiring and Connections section for important guidelines

before creating or choosing premade cables.

In The Box

1x MX-0404-HDMI Matrix

1x 12V DC 2A Power Supply (US/UK/EU/AU)

1x 3.5mm 3-pin Terminal Block

1x IR Receiver

1x Remote Control Handset (CR2025 Battery not Included)

2x Rack Mounting Brackets

2x Wall Mounting Brackets

IMPORTANT! The MX-0404-HDMI had the previous model number of EXP-MX-0404-H2. If you would like to

access previous documentation for the EXP-MX-0404-H2 click here.

Basic Wiring Diagram

Copyright © 2021 WyreStorm Technologies | wyrestorm.com

MX-0404-HDMI Quickstart Guide | 210202

UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)

[email protected]

1 of 4

WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation

process.

4K HDR 4 Input Matrix Switcher

with 4 Scaling Outputs

MX-0404-HDMI

Quickstart Guide

Remote

Control

4K Satellite Box

Wireless Router

Control System

4K Blu-ray Player

AVR

Display Devices

KEY

HDMI

Control

Power

Ethernet

Digital Audio
