MXVFullProductRange

4KHDR4:4:460HzHDBaseTMatrixSwitchers

WithZoneAudioDe-EmbedOutputs

QuickstartGuide

WyreStormrecommendsreadingthroughthisdocumentinitsentiretytobecomefamiliarwiththeproduct’sfeaturespriortostartingthe

installationprocess.

IMPORTANT!InstallationRequirements

•Visittheproductpagetodownloadthelatestrmware,documentversion,

additionaldocumentation,andcongurationtools.

•ReadthroughtheWiringandConnectionssectionforimportantwiring

guidelinesbeforecreatingorchoosingpremadecables.

•WhilethisproductsupportsCECfortheHDMIoutputs,WyreStormcannot

guaranteecompatibilitywithallformsofCECcommunication.

IMPORTANT!InstallationRequirements

•Theuseofpatchpanels,wallplates,cableextenders,kinksincables,and

electricalorenvironmentalinterferencewillhaveanadverseeffecton

signaltransmissionwhichmaylimitperformance.Stepsshouldbetaken

tominimizeorremovethesefactorscompletelyduringinstallationfor

bestresults.

•ItissuggestedtouseshieldedCat6acablingorhigherforallHDBaseT

connectionstoachievethemaximumsignaltransmissiondistanceand

reliability.Categorycablesshouldbetestedto500Mhzacrosstheentire

link.UsingCategorycablesthatdonotpassa500Mhzfrequencymay

resultinshorterdistanceandsignalloss.

•WyreStormrecommendsusingpre-terminatedHDMIcablesduetothe

complexityoftheseconnectortypes.Usingpre-terminatedcableswill

ensurethattheseconnectionsareaccurateandwillnotinterferewiththe

performanceoftheproduct.

MXVFullProductRangeQuickstartGuide|220105

INT:+44(0)1793230343|US:844.280.WYRE(9973)

[email protected]

1of2

IntheBox

1xMXVMatrixSwitcher

1xACPowerCordwithUS/UK/EU/AUpins

1xIRRemote(CR2025BatterynotIncluded)

4/6/8xIREmitters

4/6/8xIRReceivers

2xMatrixMountingBracketswithscrews

1xQuickstartGuide(thisdocument)

AdditionalIntheBox(KIT)

2xStandardHDBaseTReceivers

2xScalingHDBaseTReceivers

1xIRReceiverforMatrixIRExt.

8xReceiverMountingBracketswithscrews(2perRX)

IdentifyingProductVersions

Theseproductshavebeenreleasedundermultipleversionswhichcontain

eitherdifferentchassisdesignsand/orfeaturesets.ContentwithinthisQSG

isfortheversion2orneweroftheseproducts.Informationonother

versionscanbefoundwithinthematchingQSG.Eachproductversionis

identiedbyav#aftertheproductnumberontheproductandouter

packaging.Notethataversionoftheseproductsmaynotcontainthis

identierwhileallversionsabovev1willhavetheversionindicated.

WiringandConnections

WyreStormrecommendsthatallwiringfortheinstallationisrunandterminatedpriortomakingconnectionstotheswitcher.Readthroughthissectioninit’s

entiretybeforerunningorterminatingthewirestoensureproperoperationandtoavoiddamagingequipment.

IRTX/RXGuidelines

•UsingWyreStorminfraredemittersandreceiversisthebestwayto

ensurethatmostIRcodingformatsaretransmittedandreceivedbythe

NetworkHDsystem.Other3rdpartyemittersandreceiverscanbeused;

however,thesedevicesmustoperateinthesamemannerasthe

WyreStormdevices.

•DuetodifferencesinIRacross3rdpartycontrolsystemstheirIRports

shouldneverbeconnecteddirectlytoaNetworkHDsystemasan

incompatibilitymayexist.WyreStormoffersacablethatcompensatesfor

voltagedifferencesaswelladjustsfordifferencesinthepinsusedwithin

theport.RefertotheCAB-IR-LINKproductpageformoreinformation.

IRTXPortPinout

ConnectionforIRTX(transmit)usesa3.5mm(1/8in)monoplug.

Tip:Anode

Sleeve:Cathode (IR Signal)

IRRXPortPinout

ConnectionforIRRX(receive)usesa3.5mm(1/8in)stereojackthatoutputs

+5VDCtopowertheincludedIRreceiver.

Tip:

Ring:IR Signal

+5V DC

Sleeve:Ground (GND)

Pin 1

Pin 8

Wire colors shown follow EIA/TIA-568B standard.

Pin 1:

Pin 2:

Pin 3:

Pin 4:

Pin 5:

Pin 6:

Pin 7:

Pin 8:

White/Orange

Orange

White/Green

Blue

White/Blue

Green

White/Brown

Brown

Beoordeel deze handleiding

4.2/5 (9 Beoordelingen)

Product specificaties

Merk:	WyreStorm
Categorie:	processzor
Model:	MXV-0808-H2L
Kleur van het product:	Zwart
AC-adapterfrequentie:	50 - 60 Hz
Ondersteund audioformaat:	LPCM
Ondersteunde video-modi:	1080p, 2160p
Maximum resolutie:	4096 x 2160 Pixels
Snelstartgids:	Ja
Aantal HDMI-poorten:	10
Vermogensverbruik (max):	160 W
HDCP:	Ja
Maximale refresh snelheid:	120 Hz
Inclusief netsnoer:	Ja
HD type:	4K Ultra HD
RS-232 port:	1
HDMI versie:	2.0
Ondersteunde grafische resoluties:	1920 x 1080 (HD 1080),3840 x 2160,4096 x 2160
Aantal per verpakking:	1 stuk(s)
Kleurdiepte:	12 Bit
HDMI in:	8
HDCP versie:	2.2
Maximale afstand:	70 m
Aantal HDMI-uitgangen:	2
Aansluiting video:	HDMI
Afstandsbediening inbegrepen:	Ja
AC-ingangsspanning:	100 - 240 V
Code geharmoniseerd systeem (HS):	85176990
Consumer Electronics Control (CEC)-ondersteuning:	Ja
3,5 mm in:	Ja
Extended display identification data (EDID):	Ja
Dolby technologieën:	DTS:X, Dolby Atmos, Dolby Vision
