ASSEMBLY AND INSTALLATION
INSTRUCTIONS
P0240
NOTES: 1. Before installing, consult local electrical codeds for wiring and grounding requirements.
2.
READ
AND
SAVE
THESE
INSTRUCTIONS.
Hardware
Package
(included):
Mounting Plate (A)
Drywall Screw Green
Groundg
Wire Connector
(D)
Mounting Screw (E)
Anchor (F)
Finial (G)
(B) Screw (C)
Loop Lock (H) Chain (I)Pure Shell(J)Fishing Line(K)
Installation
Steps
Turn off the power at fuse or circuit box
1.Cut the “H” plastic buckles with scissor when
take
down
the
PE
bags.
(See
Fig.1)
2. Set holes on the wall surface for drilling.
Remove the Mounting Plate from the
Canopy by removing two finials. Drill
two set holes.Thread the anchors into
the holes, then attach the Mounting Plate
to
the
outlet
box
by
using
two
mounting
screws.Secure
the
two
dry
wall
screws
through
the
set
holes
into
the
anchors.
3.Connect
the
chain:
-
Determine
length
of
chain
needed
to
achieve
desired
fixture
height.
(To
remove
excess
chain
section,
use
pliers
to
bend
link
open.)
-
Weave
the
fixture
wires
through
the
chain,
top
loop
and
canopy.
4.Connect
both
ends
of
the
chain
to
the
loop
using
a
loop
lock.
5.Thread
the
fixture
wire
and
fixture
ground
wire
through
the
top
loop,
canopy
and
mounting
plate.
Outlet Box
Housing Ground Wire
Anchor (F)
Wire Connector(D)
Housing Wire
Mounting Plate (A)
Fixture Ground Wire
Finial (G)
Chain (I)
Socket
Bulb Type A Max.60W (not included)
Pure Shell (J)
Fixture Wire
Page 1 / 2
