ISSUE 1
1 9471021
Installation
Videos
VIP-LD222
Dual LCD Display Speaker with Flashers
VIP-LD221C
Single LCD Display Speaker with Flashers
INTRODUCTION
The VIP-LD222 Dual LCD Display Speaker with
Flashers and the VIP-LD221C Single LCD Display
Speaker with Flashers combine audio paging and
intercom with visual notifications. Bright flashers on
the bottom edge attract attention for important
announcements. Templates provide preset display
areas for easy and quick visual layout.
SPECIFICATIONS
Features
• Cost effective and versatile solutions for applications
requiring audio and visual alerts
• Multiple template options for displaying clocks,
images and messages
• Synchronized flashing when used with additional
Valcom Flashers
• Wall or Ceiling mountable
• VIP-LD222 has displays on both sides
• VIP-LD221C has the display on one side only
Video Specifications
•178° Vertical x 178° Horizontal viewing angle
• Contrast Ratio 1000:1
• White luminance 500 cd/m
2
• Full HD Resolution (1920 x 1080)
• 60 Hz Refresh Rate
• High brightness Flashers, Red, Green, Blue, White
LEDs, combine to create millions of colors
Audio Specifications
• Full duplex talkback audio with omni-directional
microphone
• Dual speakers with 5 Watt output
Activation Methods
• Valcom Site Manager server
• Valcom Interactive Console
• Valcom Group Page
• SIP Phone Call
Nominal Power Requirements
• VIP-LD222 Dual Display
IEEE 802.3bt Type 4, 90 Watts minimum
• VIP-LD221C Single Display
IEEE 802.3bt Type 3 or 4, 60 Watts minimum
Input/Output
• Two Contact Closure Inputs
• One Relay Output, Form C, Rated 1A @ 24 Vdc
• One Line Level Audio Output
• One Line Level Audio Input for local audio
Dimensions / Weight
•12.75" H x 23.75" W x 3.0" D
(32.4cm H x 60.3cm W x 7.6cm D)
Ceiling mount Height with bracket 14.0” (35.6cm)
Wall mount Width with bracket 25.0” (63.5cm)
• VIP-LD222 15.1 lbs. (6.9 kg)
• VIP-LD221C 12.5 lbs. (5.7 kg)
Environment
• Temperature: +32 to +104°F (0 to +40°C)
• Humidity: 0 to 85% non-precipitating
