1 9471027

ISSUE 1

VIP-LD221W

LCD Display Speaker with Flashers

INTRODUCTION

The VIP-LD221W LCD Display Speaker with

Flashersis an all-in-one IP endpoint combining a 22”

LCD display for visual notification with high quality

voice paging. Bright flashers on each endattract

attention for important messages. Templates provide

preset display areas for easy and quick visual layout.

SPECIFICATIONS

Features

•Cost effective and versatile solution to applications

requiring visual alerts or flashers

•Multiple template options for displaying clocks,

images and messages

•Power over Ethernet IEEE 802.3bt Type 3 or 4, (60

Wattsminimum) compatible

•Synchronized flashing when used with additional

Valcom Flashers

Video Specifications

•178° Vertical x 178° Horizontal viewing angle

•Contrast Ratio 1000:1

•White luminance 500 cd/m

2

•Full HD Resolution (1920 x 1080)

•60 Hz Refresh Rate

•High brightness Flashers, Red, Green, Blue, White

LEDs, with up to 300 lumens each

Audio Specifications

•Full duplex talkback audio with omni-directional

microphone

•Dual speakers with 5 Watt output

Activation Methods

•Valcom Site Manager server

•Valcom Interactive Console

•Valcom Group Page

•SIP Phone Call

Nominal Power Requirements

•IEEE 802.3bt, Type 3 or 4, 60 Watts minimum

(PoE++ or UPoE)

Input/Output

•Two Contact Closure Inputs

•One Relay Output, Form C, Rated 1A @ 24 Vdc

•One Line Level Audio output

•One Line Level Audio Input for local audio

Dimensions / Weight

•12.5" H x 24.3" W x 2.25" D

(31.8cm H x 61.7cm W x 5.7cm D)

• 11.0 lbs. (5.0 kg)

Environment

•Temperature: +32 to +104°F (0 to +40°C)

•Humidity: 0 to 85% non-precipitating

Operation

The VIP-LD221Wprovides visual notification, audible

notification, or both simultaneously.Messages are

created by a Valcom Site Manager and/or Interactive

Console and delivered over the network. The bright

LED flashers on each end of the display may be

activated by priority or group membership. Live voice

pagingcan be initiatedvia SIP registration to a Voice

over IP (VoIP) telephone system, or from a Valcom

voice gateway device.When idle, the display can

provide time and date using the built-in customizable

clock display templates.
