1 947464

ISSUE 1

VIP-9890A-EM

Vandal Resistant IP Emergency Talkback

Call Station

INTRODUCTION

The VIP-9890A-EM IP Emergency Talkback Call

Station allows communication to Valcom

FXS units and SIP-enabled telephone systems

via an IP network. The VIP-9890A-EM combines

a rugged talkback paging horn with a vandal-

resistant enclosure, which is ideally suited for

interior environments.

SPECIFICATIONS

Access Methods

PBX, FXO Port via Valcom FXS Network

Station Port

POTS telephone set via Valcom

FXS Network Station Port

PBX, FXS Port via Valcom FXO Network

Trunk Port

Valcom Multicast Page Group

SIP – enabled telephone system

Features

RJ-45 for network connection

1 Form C relay output

Network activity LEDs

Power over Ethernet (PoE) 802.3af

compatible

Dimensions/Weight

Speaker Assembly / Backbox:

10.0” H x 12.5" W x 4" D

(25.4cm H x 31.75cm W x 10.2cm D)

Weight: 10.75lbs. (4.89 kg)

Nominal Specifications

Horn Impedance: 45 Ohms

Output Level: 100 dB @ 4’ on axis

Relay Current: 1 Amp @ 24VDC

Nominal Power Requirements

Via 802.3af (PoE) Ethernet Switch Class 3

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

Suitable for indoor installation

Packing List

Qty

Item

1

VIP-9890A-EM Call Station

1

VSP Document

4

Tamper Resistant Hardware
