1 947778

CAUTION: To reduce the risk of electric shock,

Do not remove cover.

No user serviceable parts inside.

Refer servicing to qualified service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

ISSUE 1

VIP-9831A IP Indoor Stealth Horn

INTRODUCTION

The VIP-9831A IP Stealth Horn is a

self-contained paging system which enables voice

paging up to 300 feet from an Ethernet connection.

The VIP-9831A consists of a horn and

Network/Audio Interface board allowing stand alone

capability when used with a SIP enabled telephone

system or can be accessed from a variety of Valcom

managed VoIP products.

SPECIFICATIONS

Access Methods

PBX, FXO Port w/VIP-811

POTS telephone set w/VIP-811

PBX, FXS Port w/VIP-821

Valcom M Cast Page Group

SIP telephone system

Features

RJ-45 network connection

Network activity LEDs

Power over Ethernet (PoE) 802.3af compatible

Dimensions/Weight

9.3 "H x 15.0 "W x 5.0 "D

(23.6 cm x 38.1 cm x 12.7 cm)

Weight: 5.5 lbs (2.05 kg)

Shipping Weight: 6.0 lbs (2.24kg)

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

INDOOR USE ONLY

Power

Via 802.3af PoE Ethernet Switch: Class 3

Precautionary Designations

Packing List

QtyItem

1 VIP-9831A IP Horn

1 VSP Document

4 Mounting Screws

INSTALLATION

FCC Information

This equipment has been tested and found to

comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable

protection against harmful interference when the

equipment is operated in a commercial

environment. This equipment generates uses

and can radiate radio frequency energy and if not

installed and used in accordance with the

instruction manual, may cause harmful

interference to radio communications. Operation

of this equipment in a residential area may cause

harmful interference in which case the user will

be required to correct the interference at his own

expense.
