Pagina 1/9
Issue 9
1 947204
V-2003A - THREE ZONE PAGE CONTROL UNIT
V-2003AHF - THREE ZONE HANDSFREE
TALKBACK PAGE CONTROL UNIT
INTRODUCTION
The V-2003A provides telephone system access
to multiple zones (Up to 3) of one way paging
plus all call.
The V-2003AHF provides telephone system
access to multiple zones (Up to 3) of handsfree
talkback and/or one-way paging with a one-way
all call.
“WARNING: To reduce the risk of fire or
electric shock, do not expose this equipment
to rain or moisture.”
“WARNING: Shock Hazard - Do Not Open.”
“AVIS: Risque de Choc Electrique ne pas
Ouvrir.”
“PELIGRO: Corriente Electrica - No Abra.”
“CAUTION: To reduce the risk of fire replace
only with same type 1A, 125V fuse. 1A, 125V
may be replaced by a 0.5A, 250V provided
voltage selector is set for 230V.”
“DANGER: Afin de réduire le risque de feu,
remplacez le fusible par le même type de
fusible à 1A, 125V. On peut utiliser un fusible
à 0.5A, 250V pourvu que le sélecteur
ďalimentation soit fixé sur 230V. Ne pas
ouvrir.”
“VORSICHT: Zur verringerung von
feuergefahr die sicherung nur mit derselben
type 1A, 125V ersetzen. Statt 1A, 125V Kann
0.5A, 250V Benutzt werden, vorausgesetzt,
die spannung ist auf 230V eingestellt. Nicht
öffnen.”
“PELIGRO: Para reducir el peligro de
incendio remplazarlo unicamente con un
fusible del mismo tipo 1A, 125V. El fusible
de 1A, 125V podra ser remplazado por uno
de 0.5A, 250V si el selector de voltaje esta
puesto en 230V. No abres.”
SPECIFICATIONS
Access Method
Electronic Key System (C. O. Line Position)
PABX (Loop or Ground Start Trunk)
1A2 Key systems (400 Type Line Card
required)
600 Ohm Page Port equipped with contact
closure and DTMF dialing capability; Page
Port must be bi-directional if using V-
2003AHF.
Dedicated single line telephone(s)
Features of the V-2003A
3 zones of one-way paging
One-way all call
Integrated power supply
Supplies 20 Valcom power units (-24 VDC,
1 A) for powering speaker amplifier
assemblies
Volume controls supplied for:
Background music
Tones
Night ring/warble tone
(Closure or 90 VAC ring activated)
Time clock/single tone (Closure
activated)
Options are dip switch programmable per
zone (Music and tones)
Dial tone (Optional)
(#) Button returns dial tone
Provides audio for up to 150 Valcom
one-way speaker amplifier assemblies per
zone
2
115 VAC @ 60 Hz or 230 VAC @ 50 Hz
operation (with appropriate cord set)
AC input fused at 1 A @ 115 VAC or
0.5 A @ 230 VAC
Override page on separate tip/ring
temporarily disconnects page in progress
and issues an override busy tone to
overridden party
Normal paging is restored after override
Inhibit circuitry (Speaker cancel)
UL Listed
Additional Features Supplied by the
V-2003AHF
3 zones of handsfree talkback, one-way or
mixed paging
Dip switch programmable per zone (Music,
tones and one-way or talkback)
Pre-announce tone (Optional)
Repeated alert tone (Optional)
Two volume controls for handsfree paging
- Page (Phone to speaker)
- Receive (Speaker to phone)
Supplies 10 Valcom power units (-24VDC,
0.5 Amp) for powering one-way amplified
speakers (A reduction of 10 power units
from the V-2003A)
Priority Sequence
The V-2003A and V-2003AHF Units are
designed with the following priority (1 = highest;
5 = lowest):
___1. Time clock signal
___2. Override page
___3. System page
___4. Night right
___5. Music
Physical Description
The V-2003A and V-2003AHF are contained in
single, gray steel cases, which can be wall or
shelf-mounted.
V-2003A
Dimensions: 7.10"H x 10.00"W x 3.00"D
(18.03cm x 25.40cm x 7.62cm)
Weight: 4.1 lbs. (1.86 kg)
V-2003AHF
Dimensions: 7.10"H x 10.00"W x 3.00"D
(18.03cm x 25.40cm x 7.62cm)
Weight: 5.6 lbs. (2.54 kg)
Nominal Specifications
Input Impedance: 600 ohms
Input Level: -10 dBm
Music Source Impedance: 8 to 600 ohms
Music Input Level: -10 to -18 dBm
Output Impedance: 8 ohms (1 way)
45 ohms (Talkback)
Output level: -10 dBm (1 way)
1 W (Talkback)
DC Output: -24 VDC at 1 A (V-2003A)
-24 VDC at 0.5 A (V-2003AHF)
Nominal Power Requirements
Voltage: Current:
115 VAC 1 A
230 VAC 0.5 A
Environment
Temperature: 0 to +40 degrees C
Humidity: 0 to 85% non-condensing
Battery Backup
The V-2003A/V-2003AHF is equipped with a
standard 3-prong MOLEX connector to allow
connection of a fused output battery backup
supply (3 Amp, Valcom VPB-260 or equivalent)
in case of AC power failure. Backup time will be
a function of system usage.
NOTE: The AC line cord of the VPB-260
and the AC line cord or the V-2003A
(or V-2003AHF) should be plugged into the
same AC circuit.
OPERATION
General
Press the line key (Electronic Key System), dial
the trunk access code (PABX) or dial the page
port access code to access the
V-2003A/V-2003AHF; with dedicated single line
sets - simple go off hook. The
V-2003A/V-2003AHF will return dial tone (If so
optioned). Dial desired zone code: 1, 2, 3, or 5,
6, 7 for individual zones (1 through 3
respectively). Dial 4 or 8 for the all call of all
zones. Ringback tone (If so optioned) will be
heard in the telephone receiver. Make
announcement and hang up. The unit will
automatically disconnect from page. Ringback
tone and repeated alert tones, when optioned,
provide an alert tone to the talkback zones on a
V-2003AHF. The repeated alert tones will
broadcast every 15 seconds when the zone is
active in the handsfree mode.
