LP2902-N,LP324-N
www.ti.com
SNOSBX6C–SEPTEMBER1999–REVISEDMARCH2013
LP324-N/LP2902-NMicropowerQuadOperationalAmplifier
CheckforSamples:LP2902-N,LP324-N
1
FEATURES
DESCRIPTION
TheLP324-Nseriesconsistsoffourindependent,
2
•LowSupplyCurrent:85μA(typ)
highgaininternallycompensatedmicropower
•LowOffsetVoltage:2mV(typ)
operationalamplifiers.Theseamplifiersarespecially
•LowInputBiasCurrent:2nA(typ)
suitedforoperationinbatterysystemswhile
maintaininggoodinputspecifications,andextremely
•InputVommonModetoGND
lowsupplycurrentdrain.Inaddition,theLP324-Nhas
•InterfacestoCMOSLogic
aninputcommonmoderange,andoutputsource
•WideSupplyRange:3V<V
+
<32V
rangewhichincludesground,makingitidealinsingle
supplyapplications.
•SmallOutlinePackageAvailable
•Pin-for-pinCompatiblewithLM324
Theseamplifiersareidealinapplicationswhich
includeportableinstrumentation,batterybackup
equipment,andothercircuitswhichrequiregoodDC
performanceandlowsupplycurrent.
ConnectionDiagram
Figure1.14-LeadSOICFigure2.14-PinTSSOP
SeeNFF0014AorDPackageSeePWPackage
1
Pleasebeawarethatanimportantnoticeconcerningavailability,standardwarranty,anduseincriticalapplicationsof
TexasInstrumentssemiconductorproductsanddisclaimerstheretoappearsattheendofthisdatasheet.
2Alltrademarksarethepropertyoftheirrespectiveowners.
PRODUCTIONDATAinformationiscurrentasofpublicationdate.
Copyright©1999–2013,TexasInstrumentsIncorporated
ProductsconformtospecificationsperthetermsoftheTexas
Instrumentsstandardwarranty.Productionprocessingdoesnot
necessarilyincludetestingofallparameters.
