HD3SS6126
USB
Connector
USB
Connector
NoteBook
Dock Station
Connector
USB HOST
USB 2
Rx
DP/ DM
USB 3
USB 3
Tx
Product
Folder
Sample &
Buy
Technical
Documents
Tools &
Software
Support &
Community
HD3SS6126
SLAS975A–NOVEMBER2013–REVISEDAUGUST2015
HD3SS6126USB3.0andUSB2.0DifferentialSwitch2:1/1:2MUX/DEMUX
1Features3Description
TheHD3SS6126deviceisahigh-speed,passive
1
•IdealforUSBApplications
switchthatisdesignedforUSBapplicationstoroute
–SignalSwitchforUSB3.0(SuperSpeedUSB
bothSuperSpeedUSBRXandTXandUSB2.0DP
andUSB2.0HS/FS/LS)
andDMsignalsfromasourcetotwodestinationsor
•ThreeBidirectionalDifferentialPairChannel
viceversa.Thedevicecanalsobeusedfor
DisplayPort,PCI-Express™,SATA,SAS,andXAUI
MUX/DEMUXSwitchesAlsoSuitablefor
applications.TheHD3SS6126devicecanbeusedin
DisplayPort,PCIeGen1/2/3,SATA1.5/3/6G,SAS
eithersink-sideorsource-sideapplications.
1.5/3/6GandXAUIApplications
•SupportsDataRatesupto10GbpsonHigh-
DeviceInformation
(1)
BandwidthPath(SS)
PARTNUMBERPACKAGEBODYSIZE(NOM)
•V
CC
OperatingRange3.3V±10%
HD3SS6126WQFN(42)9.00mm×3.50mm
•Wide–3-dBDifferentialBWofMoreThan10GHz
(1)Forallavailablepackages,seetheorderableaddendumat
onHigh-BandwidthPath(SS)
theendofthedatasheet.
•UsesaUniqueAdaptationMethodtoMaintaina
TypicalApplicationDiagram
ConstantChannelImpedanceOvertheSupported
Common-ModeVoltageRange
•ExcellentHigh-bandwidthPathDynamic
Characteristics(at2.5GHz)
–Crosstalk=–35dB
–Isolation=–23dB
–InsertionLoss=–1.1dB
–ReturnLoss=–11dB
•Small3.5mm×9mm,42-PinWQFNPackage
(RUA)
•ActiveModePower=8mW
2Applications
•DesktopPCs
•NotebookPCs
•Tablets
•DockingStations
•Telecommunications
•Televisions
1
AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,
intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.
