AM263x Sitara™ Microcontrollers with Real-Time Control

1 Features

Processor Cores:

•Single, dual, and quad-core Arm

®

Cortex

®

-R5F

MCU with each core running up to 400MHz

–16KB I-cache with 64-bit ECC per CPU core

–16KB D-cache with 32-bit ECC per CPU core

–64KB Tightly-Coupled Memory (TCM) with 32-

bit ECC per CPU core

–Lockstep or Dual-core capable clusters

Memory Subsystem:

•2MB of On-Chip RAM (OCSRAM)

–4 Banks x 512KB

–ECC error protection

–Internal DMA engine support

System on Chip (SoC) Services and Architecture:

•1x EDMA to support data movement functions

•Device Boot supported from the following

interfaces:

–UART (Primary/Backup)

–QSPI NOR Flash (4S/1S) (Primary)

•Interprocessor communication modules

–SPINLOCK module for synchronizing

processes running on multiple cores

–MAILBOX functionality implemented through

CTRLMMR registers

•Central Platform Time Sync (CPTS) support with

time-sync and compare-event interrupt routers

Media and Data Storage:

•1x 4-bit Multi-Media Card/Secure Digital

(MMC/SD) interface

•General-Purpose Memory Controller (GPMC)

–16-bit parallel data bus with 22-bit address bus

–Up to 4MB addressable memory space

–Integrated Error Location Module (ELM)

support for error checking

General Connectivity:

•6x Universal Asynchronous RX-TX (UART)

•5x Serial Peripheral Interface (SPI) controllers

•5x Local Interconnect Network (LIN) ports

•4x Inter-Integrated Circuit (I2C) ports

•4x Modular Controller Area Network (MCAN)

modules with CAN-FD support

•1x Quad Serial Peripheral Interface (QSPI)

•4x Fast Serial Interface Transmitters (FSITX)

•4x Fast Serial Interface Receivers (FSIRX)

•Up to 139 General-Purpose I/O (GPIO) pins

Sensing & Actuation:

•Real-time Control Subsystem (CONTROLSS)

•Flexible Input/Output Crossbars (XBAR)

•5x 12-bit Analog-to-Digital Converters (ADC)

–6-input SAR ADC up to 4MSPS

•6x Single-ended channels OR

•3x Differential channels

–Highly Configurable ADC Digital Logic

•XBAR Start of Conversion Triggers (SOC)

•User-defined Sample and Hold (S+H)

•Flexible Post-Processing Blocks (PPB)

•10x Analog Comparators with Type-A

programmable DAC reference (CMPSSA)

•10x Analog Comparators with Type-B

programmable DAC reference (CMPSSB)

•1x 12-bit Digital-to-Analog Converter (DAC)

•32x Pulse Width Modulation (EPWM) modules

–Single or Dual PWM channels

–Advanced PWM Configurations

–Extended HRPWM time resolution

•10x Enhanced Capture (ECAP) modules

•3x Enhanced Quadrature Encoder Pulse (EQEP)

modules

•2x 4-Ch Sigma-Delta Filter Modules (SDFM)

•Additional Signal-multiplex Crossbars (XBAR)

Industrial Connectivity:

•Programmable Real-Time Unit (PRU-SS) and

PRU-Industrial Communication Subsystem (PRU-

ICSS)

–Dual core Programmable Realtime Unit

Subsystem (PRU0 / PRU1)

•Deterministic Hardware

•Dynamic Firmware

–20-channel enhanced input (eGPI) per PRU

–20-channel enhanced output (eGPO) per PRU

–Embedded Peripherals and Memory

•1x UART, 1x ECAP

•1x MDIO, 1x IEP,

•1x 32KB Shared General Purpose RAM

•2x 8KB Shared Data RAM

•1x 16KB IRAM per PRU

•ScratchPad (SPAD), MAC/CRC

–Digital encoder and sigma-delta control loops

–The PRU-ICSS enables advanced industrial

protocols including:

•EtherCAT

®

, Ethernet/IP

™

,

•PROFINET

®

, IO-Link

®

for order

–Dedicated Interrupt Controller (INTC)

–Dynamic CONTROLSS XBAR Integration

AM2634, AM2634-Q1, AM2632, AM2632-Q1, AM2631, AM2631-Q1

SPRSP74E – OCTOBER 2022 – REVISED AUGUST 2025
