G44 User Guide

This user guide provides basic instructions for setting up SEADA G44 video wall controllers using its

management software.

Document No. - -027 SD MA

Document Version: 02

G44 User Guide

Table of

Table of Table of Contents

Contents

Contents Contents

1. Product Introduction ....................................................................................................................... 3

1.1. Product profile ........................................................................................................................ 3

1.2. Product capability 3 ...................................................................................................................

1.3. Specification & Parameters ..................................................................................................... 3

2. Hardware Overview ........................................................................................................................ 5

3. G44 Software .................................................................................................................................. 6

3.1. Matrix Switch .......................................................................................................................... 6

Audio route ............................................................................................................................. 9

3.2. Advanced Switch ..................................................................................................................... 9

3.3. Signal settings ....................................................................................................................... 12

3.4. FineTune: PQ & Position ....................................................................................................... 12

3.5. OSD Control ........................................................................................................................... 13

3.6. TV Wall .................................................................................................................................. 16

3.7. Web Control .......................................................................................................................... 17

4. Front Panel .................................................................................................................................... 20

4.1. LCM display ........................................................................................................................... 20

4.2. Audio Input Select (Default: Inner) ....................................................................................... 20

4.3. Output Audio Select (Default: Inner) .................................................................................... 21

4.4. Audio Switch ......................................................................................................................... 21

4.5. Video Switch ..........................................................................................................................22

4.6. Video + Switch ....................................................................................................................... 22

4.7. Input Type Setting ................................................................................................................. 23

4.8. Output Type Setting .............................................................................................................. 23

4.9. Output Resolution Setting ....................................................................................................24

4.10. Recall ..................................................................................................................................... 24

4.11. Save As .................................................................................................................................. 25

5. Command Lines ............................................................................................................................. 26

6. Troubleshooting ............................................................................................................................ 29

6.1. No Connection ......................................................................................................................29

6.2. No Output ............................................................................................................................. 29

6.3. Black screen .......................................................................................................................... 29

G44 User Guide

1. Product Intro

Product Intro

Product IntroProduct Introduction

duction

ductionduction

1.1. Product profile

⚫ G44 video wall controller can support up to 4 inputs/4 outputs.

⚫ It supports HDMI, DVI, VGA, YPbPr, CVBS signal input/output through DVI-U jacket.

⚫ It support RS232 communication interface, through the special PC tool to control the matrix

signal switching, monitoring the working state of the matrix, set the signal resolution, etc..

⚫ Seamless switching available;

1.2. Product capability

⚫ Support 4 inputs and 4 outputs 4 L/R audio inputs and 4 L/R audio outputs;，

⚫ Support HDMI/DVI, VGA, YPbPr, CVBS input;

⚫ Support HDMI/DVI, VGA, YPbPr, CVBS output;

⚫ Support a maximum resolution of 1600 x 1200@60hz;

⚫ Support RS232 port control

⚫ Support network port control

⚫ Support IR remote control

⚫ Support front panel button control

⚫ Scalar inside, output resolution control available;

1.3. Specification & Parameters

Input

Interface

Signal

DVI-U

HDMI

HDMI -1.3

DVI

DVI 1.0

VGA

800x600,1024x768,1280x768,1280x800,1280x1024,136

0 x768,1400x1050,1600x1200,1920x1080

YPbPr

576i50,720p50,720p60,1080i50,1080i60,

1080p50,1080p60

CVBS

PAL NTSC ，

Output

Interface

Signal

DVI-U

HDMI

HDMI V1.3A

1024x768,1280x1024,1360x768,1280x720

1600x1200,1920x1080,1680x1050

DVI

DVI 1.0

1024x768,1280x1024,1360x768,1280x720

1600x1200,1920x1080,1680x1050

VGA

1024x768,1280x1024,1360x768,1280x720

1600x1200,1920x1080,1680x1050

YPbPr

1080p60 720p60，

CVBS

PAL/NTSC

Control

RS232

D-sub 9

Baud rate ：9600

S ize

W*D*H

43 220 440（mm）× （mm）× （mm）

Product specificaties

Merk:	SEADA
Categorie:	Processor
Model:	G44
Soort bediening:	Knoppen
Kleur van het product:	Zwart
Ingebouwd display:	Ja
Gewicht:	4000 g
Breedte:	480 mm
Diepte:	245 mm
Hoogte:	44.55 mm
Gewicht verpakking:	4220 g
Breedte verpakking:	565 mm
Diepte verpakking:	365 mm
Hoogte verpakking:	120 mm
Gebruikershandleiding:	Nee
Materiaal behuizing:	Metaal
Type verpakking:	Gelamineerd karton
Montage gereedschap:	Ja
Ethernet LAN:	Ja
Ondersteunde video-modi:	720i, 720p, 1080i, 1080p
Ingebouwde ventilator:	Nee
Land van herkomst:	China
Code UK-handelstarief:	84718000
Afgedankte Elektrische en Elektronische Apparatuur (AEEA) naleving:	Ja
Vermogensverbruik (max):	25 W
HDCP:	Ja
HDMI versie:	1.3a
Duurzaamheidscertificaten:	CE
Type processor:	Nee
Ingangsspanning:	100 - 240 V
Ethernet LAN, data-overdrachtsnelheden:	10,100,1000 Mbit/s
Bekabelingstechnologie:	10/100Base-T(X)
Bevat geen:	Lood
Temperatuur bij opslag:	-20 - 60 °C
Frequentie:	50/60 Hz
Luchtvochtigheid bij opslag:	10 - 90 procent
Rack-montage:	Ja
Naleving van duurzaamheid:	Ja
RJ-45 ports hoeveelheid:	1
DVI input ports:	4
DVI output ports:	4
HDCP versie:	1.4
Rackcapaciteit:	1U
Stroomverbruik (typisch):	20 W
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
Batterijen inbegrepen:	Nee
Type beeldscherm:	LCD
Vermogenstoevoer locatie:	Extern
Geschaalde resoluties:	1280 x 720,1920 x 1080,1920 x 1200
Baud snelheid:	9600 Kbit/s
RS-232/422-connector:	Ja
