Si-82 Pack 1
Centrifugal pump
Sauermann
®
part #: SI82CE01UN23
Durable pump
The Si-82 pump is designed to be easily installed whatever the layout of the premises.
Capable of evacuating up to 500 l/h, the Si-82 pump is suitable for air conditioning
units and industrial refrigeration displays.
Strong, the Si-82 tolerates charged, high temperature and acidic condensates
(pH>2.5) produced by gas condensing boilers.
Kit content
Benets
• One-piece centrifugal pump with tank (2L)
• Integrated barb end check valve ext. Ø 10 mm (3/8”)
• Plug-in power (2 m, European plug) & safety switch cord (1.5 m, bare ends)
• Straight connector ext. Ø 10 mm (3/8”) – ext. Ø 6 mm (1/4”)
• 2 screws + 2 plugs
DATA SHEET
Installation in any place
• Pump can be oor mounted, attached on a wall or
hanging from a ceiling.
Versatile
• Easily removable tank and reversible pump, to allow
mounting rather on the left or on the right of the
application and choosing the side of the water exit.
Easy electrical connection
• Plug-in power cord to facilitate installation and
maintenance.
Easy hydraulic connection
• Quarter turn easily removable check valve, designed
to facilitate Ø int. 10 mm (3/8”) hose plug in.
• 4 inlet holes Ø 30 mm (1” 3/16)
High resistance
• Oil and acid resistant oat
• Mechanical structure resistant to shocks
High performance
• Can discharge condensates up to 5 m
• Up to 500 l/h, for shorter running time
• Low sound level – quiet operation
• Column air conditioning units
• Multi cassettes
• Ducted units
• Gas condensing boilers
• High efciency gas furnace
• Refrigerating display cabinets
• Evaporators
Name #Part
Clear PVC hose
int. Ø 10 mm (3/8’’)
ACC00911: 25 m
ACC00915: Braided, 25 m
Check valve
For replacement
ext. Ø 10 mm (3/8’’)
ACC00925
Inlet rubber adapter
int. Ø 15-20-24-32-
40mm
(int. Ø 5/8”-3/4”-1”-
1”1/4 -1”½)
ACC00939
Technical specications
Accessories
Applications
Actual ow rates (l/h)
sauermanngroup.com
SI82CE01UN23_EN - 09/10/23 – Non-contractual document. We reserve the right to modify the characteristics on our products without prior notice.
Max. ow rate 500 l/h
Max. discharge head 5 m
Max pressure 5.4 m - ow rate = 0 l/h
Sound level in application at 1 m
(3.3 ft)
(Measured in Sauermann acoustic lab, pump
operating with water)
≤ 45 dBA
Mains supply 230 V~ 50 Hz – 70 W – 0.75 A
Detection levels On: 53 mm, Off: 42 mm, Safety: 64 mm
Safety switch NC 4 A resistive – 250 V
Max. condensate temperature 65 °C, 80 °C in short peak
Max. condensate acidity pH > 2.5 (Gas condensing boilers)
Thermal protection (overheating) 105 °C (auto-reset)
Operating conditions 30%: 3s ON – 7s OFF
Protection IP20
Safety standards CE, EAC, UKCA
RoHS directive Compliant
WEEE directive Compliant
Weight (including box) 2.5 kg
Packaging 4 pcs: L 400 x W 300 x H 200 mm
Pallet quantity 64 pieces
Total tube length (Ø int. 10 mm, 3/8’’)
Vertical
discharge head
5 m 10 m 20 m 30 m
1 m 380 300 240 190
2 m 310 260 200 150
3 m 240 200 145 110
4 m 150 130 80 60
5 m 30 20 0 0
Discharge head (m)
Flow rate (l/h)
