Pagina 1/9
English
Quick start guide
Operating temperature, protection of the instruments and information about storage and the battery
1 Display
•
Operating temperature*:
KT320: from -40 to +70 °C / -40 to +158 °F; KTT320: from -20 to +70 °C / -4 to +158 °F;
KCC320, KPA320, KP320 & KP321: from 0 to 50 °C / 32 to 122 °F
• KT320: IP65; KTT320: IP54; KCC320, KPA320: IP40, KP320, KP321: IP65*
• Storage temperature: from -20 to +50 °C / -4 to 122 °F
Battery power supply: 2 x lithium AA 3.6 V batteries
*With the pressure connectors plugged
2 Dimensions (mm)
Five recording modes
KISTOCK can record in 5 different ways:
• ”Immediate” mode records values according to a predened interval.
• ”Minimum”, ”Maximum” and ”Average” record automatically the calculation of minimum, maxi-
mum or average of measured values during an interval of recording.
• ”Monitoring” mode allows to get an accurate history report during error events to help troubleshoot-
ing, without stopping the measurement logging. To proceed this way, you just have to dene:
- a record interval to be used whilst the readings are beyond the setpoints
- a record interval for the values measured during each reading beyond the setpoints
• Furthermore, you can also let your KISTOCK record non-stop (”loop” recording option).
Four types of dataset start
Once your recording mode has been set, you can launch your dataset:
• With a delayed start (with predened date and time)
• With the software
• With push-button
• With ”Online” option. In this case, your datasets are directly sent, saved and displayed on your PC in
real time.
Six types of dataset stop
You can stop your dataset:
• According to a date and time (if it was started the same way)
• According to a period
• According to a predened number of recording points
• Once the storage capacity is full
• With ”Stop” option of the software
• By holding ”OK” key during 5 seconds, if this function has been previously activated by the software
5 Recorder function
Reference Parameters
KT 320 Temperature, humidity, current, voltage, electric pulses
KTT 320 Temperature
KCC 320 Temperature, humidity, atmospheric pressure, CO
2
KPA 320 Temperature, humidity, atmospheric pressure
KP320, KP321 Differential pressure
°C: Temperature in °Celsius.
°F: Temperature in °Fahrenheit
%RH: Relative humidity
DATASET is nished.
Indicates that one value is being recorded.
It ashes: the DATASET did not start already.
Flashing slowly: DATASET is between 80 and 90% of the storage capacity.
Flashing quickly: DATASET is between 90 and 100% of the storage capacity.
Constant: storage capacity full.
Constant: indicates that the batteries have to be replaced.
Indicates the channel number which is measuring.
Screen actualisation of measured values.
The displayed values are the maximum/minimum values recorded
for the channels displayed.
Indication of the direction of exceeding the threshold in the
recorded measurement
REC
END
BAT
ACT
MIN
MAX
1 2
3 4
FULL
KT320 KTT320 KCC320, KPA320
3 Connections
KP320, KP321
PC connection
Micro-USB
connector
KT 320: 2 mini-DIN connections
KTT 320: 4 mini-thermocouples
connections
KP320, KP321: Two pressure
connections
