C.H. PUMP CONTROLLER

Model: NPC1

04/2026

Introduction

Product compliance

FUNCTION

Product description

Praca ręczna

Controller operation

Wiring diagram

Alarm

Technical data

Histeresis

Additional functions

Safety information

The NPC1 controller is designed to control the water pump in the

central heating circuit. The controller’s function is to switch the pump

on if the temperature exceeds the set point, and to switch it o if the

boiler cools down (due to the boiler going out). This prevents

unnecessary pump operation and extends its service life, which also

saves electricity. Depending on the degree of boiler utilisation, savings

can reach up to 60%. This increases the pump’s reliability and reduces

the costs associated with operating the system.

This function allows you to check whether the connected pump is working by

pressing the and buttons simultaneously.

Pressing the buttons again will switch the pump o.

1.

Power supply indicator

2.

C.H. pump operation indicator

3.

Display

4.

5.

Menu button

7.

Temperature sensor

8.

Pump power supply

9.

Controller power supply

10.

ON/OFF power supply switch

The controller is equipped with an sound alarm which signals too high

temperature on the boiler (above 90°C).

This is the dierence between temperature of the pump start and the

temperature of return to standby. Controller has a constant hysteresis

of 2°C. For example, after setting the setpoint temperature at 50°C,

pump will be turned on after exceeding 50°C, and will be turned o

when the temperature will drop to 48°C.

Controller has an „anti-stop” function which protects pump against

lime scale when there is no heating season. Pump is turned on every

14 days for 15 seconds.

An additional protection is the frost protection function, which runs pump

permanently when temperature on the sensor drops below 5°C.

Use in accordance with the regulations in force in your country and

within the EU. The device must be used for its intended purpose.

It must not be used in conditions where water vapour condensation

occurs, nor must it be exposed to water.

This product is for indoor use only.

The controller must be installed by a qualied person, in accordance

with the regulations in force in the relevant country and within the

EU. Before carrying out any work involving the power supply

(connecting cables, installing the device, etc.), ensure that the

controller is not connected to the mains! Incorrect connection of

cables may damage the controller.

230 V

NPC1

Input rated voltage:230 V / 50Hz ±10%

Rated frequency2 W

Working temperature-10 do +50°C

Max load of the pump output

Temperature measurement range

6 A

0 do 99°C

Setpoint temperature range5 do 80°C

Sensor temperature range−10 do +120 °C

Sensor cable length1,2 m

123

4

5

6

789

10

T

T[°C]

t

90°C

C

91°C

2°C2°C

ALARM

(sound alarm)

PUMP OPERATION

HEATING

C - set pump start-up temperature

www.saluscontrols.com

SALUS Control is a member of the Computime Group.

In line with its policy of continuous product development, SALUS Controls reserves the

right to change the specications, design and materials of the products listed in this

brochure without prior notice.

Setpoint temperature is changed by pressing the button.

Display should indicate a ashing „C” letter. At this point it is possible to

change the desired setpoint temperature using or buttons.

After a few seconds, the controller will go into operating mode and display

the current boiler temperature.

MANUFACTURER:

SALUS Controls plc,

Units 8-10,

Northeld Business Park,

Forge Way, Parkgate

Rotherham, S60 1SD

United Kingdom

UK: [email protected]

PL: [email protected]

DE / NL: [email protected]

FR: [email protected]

RO: [email protected]

DK: [email protected]

IMPORTER:

Salus Controls

European Distribution sp.z o.o.

ul. Szamocka 8, piętro 6.,

01 748 Warszawa,

Poland

QUICK GUIDE

This product complies with the following European directives: GPSR

2023/988/EU, EMC 2014/30/EU, LVD 2014/35/EU, RoHS 2017/2102/EU,

and SVHC 215. The full text of the EU Declaration of Conformity is available

at the following web address: www.saluslegal.com

PN-EN 60730-1:2016-10+A1:2019-07+A2:2022-10

PN-EN IEC 60730-2-9:2019-06+A1:2019-06+A2:2021-01

PN-EN 61000-3-2:2019-04+A1:2021-08

PN-EN 61000-3-3:2013-10+A1:2019-10+A2:2022-04

PN-EN 50419:2023-05

PN-EN IEC 63000:2019-01

Increasing setpoint

temperature or value

6.

Decreasing setpoint

temperature or value

Full error list:

E1 - short circuit in the C.H. sensor circuit

E2 - broken C.H. sensor

MULTILANGUAGE

MANUAL
