The World’s best kits.
®
MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 12/8/22 INST108-FD5CH
INSTALLATION INSTRUCTIONS
108-FD5CH
Patent # 10,579,232
Attention!With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections are secure before
cycling the ignition to test this product.
KIT FEATURES
• Designed specifically for the Pioneer DMH-C5500NEX 8-inch radio
• Included interface for climate and steering wheel functions
• Integrated passenger airbag indicator
• Touchscreen display for climate and personalization features
• Painted charcoal
KIT COMPONENTS
• A) Radio trim panel (with touchscreen display) • B) Radio brackets • C) Engine start/stop circuit board and cover
• D) Engine start/stop trim
• E) (6) Phillips screws
• F) (4) Panel clips • G) USB cable • H) HVAC interface and wiring harness (not shown) • I) Antenna adapter (not shown)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 9/32” socket wrench • Cutting tool
• Torx T-10 screwdriver
TABLE OF CONTENTS
Dash Disassembly ..............................................2-4
Kit Preparation ....................................................5-7
Kit Assembly ..........................................................8
Axxess Interface installation ............................9-17
Final Assembly ......................................................13
WIRING & ANTENNA CONNECTIONS
Wiring Harness: Axxess interface built
into touchscreen
Antenna Adapter: Included with kit
Ford Mustang (with 4.2” screen) 2015-Up
AB
E
CD
FG
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
