INSTALLATION SHEET
VL60624
START FROM HERE
•
Make sure power is completely off at the fuse box.
•
Have your fixture installed by a qualified licensed electrician
•
Prepare everything in a clear area.
•
Wear gloves at all times during this installation.
•
Read instructions carefully before you start assembly.
•
Keep this instruction sheet for future reference.
Technical Support: 1-855-855-8926
LED Vanity Light
19054 28th Avenue Surrey, BC Canada V3Z 6M3
T: 604 538 7162 TF: 1-855 85 KUZCO F: 604 538 7196
W: kuzcolighting.com
(Octagon junction box install)
(Octagon junction box install)
(Single gang box install)
(Single gang box install)
1a.
1b.1g.
1d.4a.
2a.2b.
1a.1b.1c.1d.
1f.
1h.
1g.
2b.2a.
4a.
1e.
20210512
1.
2.
3.
4.
1.
2.
3.
4.
Remove the fixture from its original packaging. Next,
remove the mounting plate from the canopy by (1g) (2a)
removing canopy screws (2b)
Secure the universal mounting plate to the electrical (1c)
junction box with junction box screws provided (1a)(1d)
in the hardware package. Secure backplate to (1f)
mounting plate with screws . Attach backplate (1g)(1e)
(1f) 1g) and mounting plate (assembly to universal
mounting plate with screws (1c)(1h)
Make proper electrical connections ( to “L”, blackhot
whiteground“GND”) to “N”, neutral to with wire nuts
(1b) provided in hardware package and place driver
(4a)(2a) inside canopy
Attach the canopy to mounting plate and secure (2a) (1g)
with canopy screws (2b)
Remove the fixture from its original packaging. Next,
remove the mounting plate from the canopy by (1g) (2a)
removing canopy screws (2b)
Secure the mounting plate to the electrical junction (1g)
box with junction box screws provided in the (1a)(1d)
hardware package
Make proper electrical connections ( to “L”, blackhot
whiteground“GND”) to “N”, neutral to with wire nuts
(1b) provided in hardware package and place driver
(4a)(2a) inside canopy
Attach the canopy to the mounting plate and (2a) (1g)
secure with canopy screws (2b)
Please Note:
• This Kuzco LED fixture comes with pre-wired LED module(s)
• Unless instructed, Do Not touch any part of the LED module(s) as any unnecessary
contact with the module could cause permanent damage
• For dimming, an ELV (Electronic Low Voltage) or TRIAC type of dimmer is required
• 120V input
