ALSSEMBY TRUONINSCTIS
WD CAISARNINGANS UTON
• Make sure POWER is at the fuse boxCOMPLETELY OFF
• Have your fixture installed by a qualified licensed electrician
• Prepare everything in a clear area
• Wear gloves at all times during this installation
• Read instructions carefully before you start assembly
• Keep this installation sheet for future reference
WV347104
TEHNICCRTAL SUPPO
1.855.855.8926
ticsualora.comechnalpport@litighng
NOTICE
•afeansctinedn htor The importnt sagurds and itruonouts li ithis see cannot cve
all ssis cce pobitiatile condons a sindtuonthato may urt st b. Imuundtooersd
thutonndrttormufoThtruonat cai a ceaie acnr cafs st be llwe. odese insctis are
proforourndghomndthtrvided y say afet we hily ecrme atnd a licese, ained
eleciciaall is trnnst ithunit.
•fded bed tnstdtaa d This ixture is esigntoe mounton a correcly ialle sndrdroun
orgonbothroughngbothfrThbomu octa x OR a wiri x wi a plaster ame. e x st be
sece e il. sswaurely me sounted tothtructurofth budingThe crobar ha andrdre
sdld buddirti f t may upplie shoue se, ecly mountngthe ixe turtothoute lebox
make i imtpossible ectoorr c
t fe.ly alignthe ixtur
Wall Lamp
CANADA:
USA: 3035 E. Lone Mountain Rd - Las Vegas, NV, 89081
wwligtingcowlora.ah.m
20230619
P:
1.855.855.8926
19054 28th Avenue Surrey - BC V3Z 6M3
ALSSEMBY TRUONINSCTIS
Step 1
Remove fixture from its original package.
Step 2
Separate mounting plate (1c) from canopy (2a) by removing canopy screws
(2b).
Step 3
Attach mounting plate (1c) to electrical junction box (1a) using junction box
screws provided (1e) in hardware package.
Step 4
Make proper electrical connections ( to to “N”, blackhot white“L”, neutral
ground GNDto “”) with wire nuts provided in hardware package and (1b)
place driver (4a) in canopy (2a).
Step 5
Secure filament (5c) to fixture (5b) by threading clockwise. Attach filament
end (5d) to filament (5c) with end cap (5e). Align holes on fixture (5b) and
filament end (5d) with holes on shade (6b), secure with screws (6a).
Step 6
Secure canopy (2a) to mounting plate (1c) with canopy screws (2b).
Step 7
Use dimmer switch (3a) to turn on/off.
Step 8
Use lock (5a) to unlock fixture to adjust tilt and lock in place.
You are now ready to enjoy your fixture.
1a.1b.1c.
4a.2b.3a.
1e.2a.
5a.5b.5c.5d.5e.
6a.6b.
Please Note:
•This Alora LED fixture comes with pre-wired LED module(s)
•Unless instructed, Do Not touch any part of the LED module(s) as any unnecessary contact with
the module could cause permanent damage
•For dimming, an ELV (Electronic Low Voltage) or TRIAC type of dimmer is required
• 120V input
